Husqvarna 111B User Manual

English – 27
TECHNICAL DATA
Note 1: The power rating of the engine indicated is the average net output (at specified rpm) of a typical production engine for the engine model measured to SAE
standard J1349/ISO1585. Mass production engines may differ from this value. Actual power output for the engine installed on the final machine will depend on the
operating speed, environmental conditions and other values.
Note 2: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC.
Note 3: Noise pressure level according to EN 836. Reported data for noise pressure level has a typical statistical dispersion (standard deviation) of 1.2 dB(A).
Note 4: Vibration level according to EN 836. Reported data for vibration level has a typical statistical dispersion (standard deviation) of 0.2 m/s
2
(steering wheel) and
0.8 m/s
2
(seat).
Rider 111 B5 Rider 111B
Dimensions
Length without cutting unit, mm/ft 1734/5.69 1734/5.69
Length with cutting unit, mm/ft 2100/6.89 2100/6.89
Width without cutting unit, mm/ft 785/2.56 785/2.56
Width with cutting unit, mm/ft 883/2.90 883/2.90
Height, mm/ft 1084/3.56 1084/3.56
Operating weight with cutting deck, kg/lb 165/364 165/364
Wheel base, mm/ft 800/2.62 800/2.62
Tyre dimensions 155/50-8 155/50-8
Air pressure, rear - front, kPa / bar / PSI 60 (0,6/8,5) 60 (0,6/8,5)
Max. gradient 10
° 10°
Engine
Brand / Model Briggs & stratton/2158 Briggs & stratton/2158
Nominal engine output, kW (see note 1) 6,8 6,8
Displacement, cm
3
/cu.in 344/21 344/21
Max.motor speed, r/min 3000 ± 100 3000 ± 100
Fuel, minimum octane grade lead-free 85 85
Fuel tank capacity, litre 2,65 2,65
Oil, class SJ-CF SAE 5W/30 or SAE 10W/30 SAE 5W/30 or SAE 10W/30
Oil tank capacity, litre/USqt 1,4/1,5 1,4/1,5
Starting Electric starter Electric starter
Electrical system
Type 12 V, negative earthed 12 V, negative earthed
Battery 12 V, 20 Ah 12 V, 20 Ah
Spark plug Champion QC12YC Champion QC12YC
Electrode gap, mm/inch 0,75/0,030 0,75/0,030
Main fuse Flat pin, 15 A. Flat pin, 15 A.
Noise emissions and cutting width
(see note 2)
Sound power level, measured dB(A) 98 98
Sound power level, guaranteed dB(A) 99 99
Cutting width, cm/inch 85/33,5 85/33,5
Sound levels
(see note 3)
Sound pressure level at the operators ear, dB(A) 86 86
Vibration levels
(see note 4)
Vibration level on the steering wheel, m/s
2
2,4 2,4
Vibration level in the seat, m/s
2
0,7 0,7
Transmission
Brand Peerless MST205 Hydrogear T2
Oil, class SF-CC SAE 80W/90 SAE 20W/50
Number of forward gears 5 -
Number of reverse gears 1 -
Forward speed, km/h. 0-7 0-7
Reverse speed, km/h 0-3 0-5
Cutting unit
Type BioClip unit BioClip unit
Cutting heights, 5 positions, mm/inch 25-70 / 1-2 3/4 25-70 / 1-2 3/4
Blade length, mm/inch 430/17 430/17
