24 – English
Maintenance
Cleaning
Clean the machine directly after use. It is much easier to wash
off grass cuttings before they dry.
Oily dirt can be removed using a cold degreasing agent.
Spray on a thin layer.
Rinse at normal water pressure.
Do not direct the jet towards electrical components or
bearings.
Do not rinse hot surfaces such as the engine and exhaust
system.
It is recommended that you start the engine and run the
mower for a short period after cleaning, so that any remaining
water is blown off.
Lubricate the machine if necessary after cleaning. Carry out
extra lubrication when the bearings have been exposed to a
degreaser or a water jet.
There is a major risk of water penetrating into bearings and
electrical connections. Corrosion attack can result, which will
lead to running problems. Cleaning additives generally
aggravate the damage.
Removing of the machine hoods
Engine cover
Pull the seat forward to its foremost position. Fold up the seat.
Pull the snap catches on the engine cover backwards. The
snap catches are located on the inside of the engine frame.
Open the engine cover forwards.
Front cover
Release the clip on the front hood and lift off the fender.
The front cover is secured to the unit frame with two hooks.
Right-hand fender
Remove the accelerator knob (1), screws (2 and 3), and
remove the cover.
Left-hand fender
Remove the screws holding the wing cover (2) and lift off the
cover.
Transmission cover
Undo the two screws (one on each side) and lift off the
transmission cover.
IMPORTANT INFORMATION
Avoid using a high pressure washer or a steam cleaner.
