Husqvarna Rider 111B User Manual

10 – English
WHAT IS WHAT?
Location of the controls
15
2
4
3
678
141310 11 12
9
5
1
1 Product and serial number plate
2 Lever to disengage the drive, Rider 111B
3 Battery
4 Throttle control/choke control
5 Gear shift lever, 111 B5
6 Ignition lock
7 Lifting lever for the cutting unit
8 Speed limiter for reversing, Rider 111B
9 Speed limiter for driving forward, Rider 111B
Parking brake, Rider 111B5
10 Cutting height adjustment lever
11 Parking brake, Rider 111B Clutch pedal, Rider 111B5
12 Lock button for the parking brake, left side on Rider 111B,
r
ight-hand side on Rider 111B5.
13 Seat adjustment.
14 Cover lock
15 Fuel cap

Husqvarna Rider 111B Specifications

General

Engine manufacturer	Briggs & Stratton
Cutting width	85 cm
Cutting Height Adjustment	Central
Drive System	Rear-Wheel Drive
Weight	193 kg
Fuel Tank Capacity	4 l
