24 – English
Maintenance
6 Tension the belt with the belt adjuster.
7 Install the belt cover.
8 Set the cutting deck height control in any of the positions
1-5.
Checking the blades
To achieve the best mowing results it is important that the
blades are undamaged and well-sharpened.
Check that the blades’ attachment screws are tight.
• Put the unit in the service position, see Service position
for the cutting unit.
The blades should be balanced after sharpening.
Damaged blades should be replaced when hitting obstacles
that result in a breakdown. Let the service centre assess
whether the blade can be sharpened or must be replaced.
Replacing the blades
• Put the unit in the service position, see Service position
for the cutting unit.
• Remove the equipment frame.
• Lock the blade with a wooden block. Loosen the blade bolt
and remove the blade bolt, the washer and the blade.
• Assemble the parts in the reverse order.
• Tightening torque 45-50 Nm (4.5-5 kpm/32-36 lbft).
Removing the BioClip plug
To change a Combi deck from the BioClip function to a cutting
deck with rear ejection, remove the BioClip plug, which is
located under the unit, attached with a screws.
1 Put the unit in the service position, see Service position
for the cutting unit.
2 Loosen the screw holding the plug and remove it.
3 Fit cutting unit.
4 Fit the BioClip plug in the reverse order.
IMPORTANT INFORMATION
Replacing or sharpening the blades should be conducted
by an authorised service workshop.
!
WARNING! Do not use blades that are
cracked, chipped, or otherwise show signs
of damage or severe wear. Replace the
blades. The risk increases if the blades are
poorly balanced.
!
WARNING!
Always use genuine parts.
15mm
