14 WHEELS, TIRES
164
S01006-10
– Lay the rear wheel on a workbench with the rear sprocket
facing upwards and insert the wheel spindle in the hub.
–
To check play
A
, hold the rear wheel tight and try to turn
the rear sprocket with your hand.
Info
Measure the play on the outside of the rear sprocket.
Play of damping rubber
pieces on rear wheel
≤ 5 mm (≤ 0.2 in)
»
If clearance
A
is larger than the specified value:
– Change all the damping rubber pieces of the rear hub.
Finishing work
– Install the rear wheel. ( p. 159)
– Remove the rear of the motorcycle from the wheel stand.
( p. 102)
– Check the chain tension. ( p. 120)
