TECHNICAL DATA 22
245
Screw, cylinder head M10 Tightening sequence:
Tighten diagonally, beginning with
the rear screw on the timing chain
shaft.
1st stage
15 Nm (11.1 lbf ft)
2nd stage
30 Nm (22.1 lbf ft)
3rd stage
45 Nm (33.2 lbf ft)
4th stage
60 Nm (44.3 lbf ft)
Thread greased
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft)
Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw plug, water pump drain
hole
M10x1 15 Nm (11.1 lbf ft)
Screw, unlocking of timing chain
tensioner
M10x1 10 Nm (7.4 lbf ft)
Spark plug outside M10x1 11 Nm (8.1 lbf ft)
Spark plug inside M12x1.25 18 Nm (13.3 lbf ft)
Coolant temperature sensor on
the cylinder head
M12x1.5 12 Nm (8.9 lbf ft)
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
