HUSTLER Super Mini Z Parts Manual

302620 8/06 7-7
Blade Spindle Assembly Breakdown
NOTES:
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 783548 783548 1 BLADE SPINDLE RETAINING RING
2 783555 783555 2 BLADE SPINDLE BEARING
3 783530 783530 1 BLADE SPINDLE SPACER
4 783514 783514 1 BLADE SPINDLE HOUSING
5 783522 783522 1 BLADE SPINDLE SHAFT
1
2
2
3
4
5
