4-1
302638 Rev 1/05
MAINTENANCE
MAINTENANCE LOCATOR
CHART
1. Engine Oil Fill & Dipstick
2A. Fuel Filter (Kawasaki)
2B. Fuel Filter (Honda)
3. Engine Air Cleaner
4. Engine Oil Drain Plug
5. Battery
6. Fuel Tanks
7. Hydraulic Oil Reservoir
8. Deck Pusher Arm Zerks (2)
9. Hydraulic Oil Filter
10. Gauge Wheel Bearing Zerks (2)
11. Engine Oil Filter
12. Deck Height Pivot Zerks (4)
13. Park Brake Switch
14. Drive Tire
15. Pump Idler Zerk (1)
16. Deck Belt
17. Pump Belt
18. Blades
19. Hydraulic Oil Heat Exchanger
6
11
2A
4
3
12
16
10
12
10
5
13
7
1
6
13
12
12
Figure 4-1
18
18
8
8
16
19
2B
14
9
14
17
15
Viewed from bottom of tractor
