230V CE INSTALLATION
2-12
230V CE Installation Manual
The 230 Volt CE conversion is now complete. See the Powermax Operator Manual for further
instructions to setup, operate and maintain the Powermax system.
Line Voltage Disconnect Box and Fuse
Use a line disconnect box for each power supply. This disconnect box allows the operator to turn the
power supply off quickly in an emergency situation. The switch should be located on a wall near the
power supply, and should be easily accessible to the operator. The interrupt level of the switch must
be equal to or exceed the continuous rating of the fuses. Use slow-blow fuses according to the power
requirements listed below.
Input Input Current Recommended
Voltage Phase @ 6.6 kw Output Slow-Blow Fuse Size
230 VAC 3 30 amps 40 amp
