Hypontech HPS-5000D User Manual

15 Warranty
The factory warranty card is enclosed with the package, please keep well the factory
warranty card. When the customer needs warranty service during the warranty
period, the customer must provide a copy of the invoice, factory warranty card, and
ensure the electrical label of the inverter is legible. If these conditions are not met,
HYPONTECH has the right to refuse to provide with the relevant warranty service.

Hypontech HPS-5000D Specifications

General

Model	HPS-5000D
Rated Power	5000 W
Max. DC Power	5500 W
Input Voltage	360 V
Max. DC Voltage	550V
Start Voltage	120 V
Number of MPPT Trackers	2
Max. Input Current per MPPT	11 A
Number of DC Inputs per MPPT	1
Max. AC Power	5000 W
Output Voltage	230 V
AC Voltage Range	180-280V
Frequency	50/60 Hz
Rated Grid Frequency	50/60 Hz
Power Factor	>0.99
THDI	<3%
DC Switch	Yes
Protection Degree	IP65
Cooling Method	Natural Convection
Cooling	Natural Convection
Communication	RS485, Wi-Fi (optional)
Weight	15 kg
Protection Features	Overvoltage, Overcurrent
Operating Temperature Range	-25°C to +60°C
Operating Temperature	-25°C to +60°C

Summary

Safety

2.1 Intended use

Details the proper applications and operating conditions for the HPS inverters.

2.3 Important safety information

Provides critical safety warnings for personnel and supervision of children.

Mounting

4.1 Ambient conditions

Specifies environmental requirements and minimum clearances for inverter installation.

4.2 Selecting the mounting location

4.3 Mounting the inverter with the wall bracket

Step-by-step instructions for securely mounting the inverter using the provided bracket.

Electrical Connection

5.3 AC connection

Details cable requirements and specifications for connecting the inverter to the AC grid.

5.3.3 Residual current protection

5.3.5 Rating of miniature circuit-breaker

5.4 DC Connection

Details the requirements and procedures for connecting the DC input to the inverter.

5.4.1 Requirements for the DC Connection

5.4.2 Assembling the DC connectors

Step-by-step guide for assembling DC connectors, including cable preparation and crimping.

5.4.3 Connecting the PV array

Instructions for safely connecting the PV array to the inverter, including polarity checks.

Communication

6.3 Active power control with smart meter

Commissioning

7.1 Electrical checks

Lists essential electrical tests for grounding, voltage, polarity, and insulation before commissioning.

7.2 Mechanical checks

Outlines mechanical checks for inverter mounting, cover, and cable gland security.

7.3 Start-Up

Describes the inverter start-up procedure, including indicator lights and operational states.

Disconnecting the Inverter from Voltage Sources

Operation (optional)

Technical Data

10.1 Electrical data

10.2 Safety regulations

10.5 Efficiency

10.7 Tools and torque

Troubleshooting

Maintenance
