GROUP 1 COMPONENT LOCATION
SECTION 7 ELECTRICAL SYSTEM
18
2
3
4
5
9
8
6
11 12 13 14 15 16
17 19
7
10
1
1 Battery
2 Flasher lamp
3 Work lamp
4 Combination switch
5 Horn assembly
6 Back buzzer
7 License lamp
8 Rear lamp
9 Combination lamp
10 Beacon lamp
11 Forward-reverse lever
12 Operating panel
13 Start switch
14 Horn button
15 Switch assembly
16 Fuse box
17 Flasher unit
18 OPSS unit
19 Buzzer
15L7AEL01
