GROUP 1 STRUCTURE
GROUP 1 STRUCTURE
SECTION 8 MAST
SECTION 8 MAST
1. 2 STAGE MAST (V MAST)
1. 2 STAGE MAST (V MAST)
2
Frame
10
Lift cylinder
7
4
6
5
Lift cylinder
8
3
9
11
Carriage
2
7
11
11
110D7EMS01
1 Outer mast
2 Roller bearing
3 Tilt cylinder pin
4 Mast mounting pin
5 Lift chain
6 Anchor bolt
7 Side roller bearing
8 Inner mast
9 Chain sheave bearing
10 Anchor bolt
11 Roller bearing
