8-1
1. SPECIFICATION TABLE
8. SPECIFICATIONS
B
D
F
A
L
T
I
M
H
K
C'
C
G'
E
W
P
R
G
160D9LSP01
Model Unit 160D-9L
180D-9L
Capacity kg (lb) 16000 (35300)
18000 (40000)
Load center R mm (in) 1200 (47.2)
900 (35.4)
Weight (Unloaded) kg (lb) 23954 (52810)
Fork
Lifting height H
mm (ft · in) 3020 (9' 11")
Free lift I
mm (ft · in) 0
Lifting speed (Unload/Load)
mm/sec 450/350
285/420
Lowering speed (Unload/Load) mm/sec 390/430
300/420
LÝWÝT L,W,T mm (in) 2450Ý250Ý100 (100Ý9.8Ý3.9)
Mast
Tilt angle (forward/backward)
C/C’
degree 10/10 (15/10 opt)
Max height K
mm (ft · in) 4665 (15' 3")
Min height M
mm (ft · in) 3200 (10' 6")
Body
Travel speed (Unload)
km/h 35.2
Gradeability (Load)
degree (%) 17.2 (31)
16.4 (29.4)
Min turning radius (Outside) E mm (ft · in) 5220 (18' 1")
ETC
Operating pressure
kgf/cm
2
230
Hydraulic oil tank
˶ (U.S.gal) 203 (53.6)
Fuel tank
˶ (U.S.gal) 276 (72.9)
Overall length A
mm (ft · in) 5564 (18' 3")
Overall width P
mm (ft · in) 2540 (8' 4")
Cabin height B
mm (ft · in) 3075 (10' 1")
Ground clearance (Mast) D
mm (in) 245 (9.6)
Wheel base F
mm (ft · in) 3750 (12' 4")
Wheel tread front/rear G/G'
mm (ft · in) 1860/2033 (6' 1"/6' 8")
