Hyundai HYM430SPR User Manual

22
Specifications
NOTE - All machines are tested and inspected so there may be some residual oil left in the
machine so please fill with caution.
MODEL HYM430SPR HYM480SPR HYM530SPR
Engine Type HYUNDAI IC140V HYUNDAI IC140V HYUNDAI IC200V
Engine Size 139cc 139cc 196cc
Fuel Tank Capacity 1L 1L 1L
Fuel Type Straight Unleaded
Petrol
Straight Unleaded
Petrol
Straight Unleaded
Petrol
Oil Capacity
Oil Type
600ml
SAE 30 OR 15W40
600ml
SAE 30 OR 15W40
600ml
SAE 30 OR 15W40
Rated Speed 3000rpm 3000rpm 3000rpm
Rated Power 2.6kW 2.6kW 4.2kW
Drive Type Self-Propelled Self-Propelled Self-Propelled
Start Method Recoil Start Recoil Start Recoil Start
Height Adjustment 6 Position 6 Position 6 Position
Cutting Height 25-75mm 25-75mm 25-75mm
Cutting Width 420mm 480mm 525mm
Grass Collector Type Half Plastic With
Polyester Bag
Half Plastic With
Polyester Bag
Half Plastic With
Polyester Bag
Grass Collector Volume 45L 70L 70L
Deck Material
Measured Sound Level
Guaranteed Sound Level
Steel
94dB(A)
96dB(A)
Steel
94dB(A)
96dB(A)
Steel
97dB(A)
98dB(A)
Vibration Value 5.361m/s2 K=1.5 m/s² 6.062m/s2 K=1.5 m/s² 11.437m/s2 K=1.5 m/s²
Dimensions (L x W x H) 1300 x 480 x 1030mm 1530 x 620 x 1100mm 1550 x 650 x 1100mm
Start Method Recoil Start Recoil Start Recoil Start
Handle Type Soft Grip Handle Soft Grip Handle Soft Grip Handle
Weight 32kg 37.2kg 38.5kg

Hyundai HYM430SPR Specifications

General

Brand	Hyundai
Model	HYM430SPR
Category	Lawn Mower
Language	English
