Hyundai i30 User Manual

7-67
7
Maintenance
Driver's side fuse Panel
Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected
F1 MODULE 5
MODULE
5
7.5A
Crash Pad Switch, Electro Chromic Mirror, MTS E-Call Module, Audio,
A/V & Navigation Head Unit, A/C Control Module, A/T Shift Lever Indicator,
Console Switch RH, DC-DC Converter, Head Lamp LH/RH, Active Air Flap Unit,
Auto Head Lamp Leveling Device Module, Front Seat Warmer Control Module,
Front Air Ventilation Seat Control Module, Driver IMS Module
F2 MODULE 3
MODULE
3
7.5A Driver/Passenger Door Module, BCM, Sport Mode Switch
F3 SUNROOF 1
1
20A Panorama Sunroof
F4 TAILGATE 10A Tail Gate Relay
F5
POWER
WINDOW LH
LH
25A
Power Window LH Relay, Driver/Passenger Safety Window Module,
Rear Power Window Switch LH, Rear Safety Window Module LH
F6 MULTIMEDIA
MULTI
MEDIA
15A Audio, A/V & Navigation Head Unit, DC-DC Converter
F7
POWER
WINDOW RH
RH
25A
Power Window RH Relay, Driver/Passenger Safety Window Module,
Rear Power Window Switch RH, Rear Safety Window Module RH
F8
POWER
SEAT DRIVER
DRV
25A Driver Seat Manual Switch, Driver IMS Module
F10 MODULE 4
MODULE
4
7.5A
Lane Keeping Assist Module, Rear Parking Assist Buzzer, Stop Lamp Switch,
Blind Spot Detection Radar LH/RH, BCM, Electric Parking Brske Switch,
Autonomous Emergency Braking Module
F11 SMART KEY 2
SMART
KEY
2
7.5A Smart Key Control Module, Immobilizer Module
F12 SUNROOF 2
2
20A Panorama Sunroof
