7-75
7
Maintenance
Engine compartment fuse panel
Fuse No. Fuse Name Symbol Fuse Rating Circuit Protected
F23
COOLING
FAN 2
2
40A RLY.9, RLY.2 (Gasoline)
F24 B+1
1
40A IGPM (Leak Current Autocut Device, Fuse : F21, F24, F27, F33)
F25 DCT 1
DCT
1
40A TCM
F26 DCT 2
DCT
2
40A TCM
F27
BURGLAR
ALARM HORN
10A ICM Relay Box (Burglar Alarm Horn Relay)
F29 ABS 1
1
40A ABS Control Module, ESP Control Module, Multipurpose Check Connector
F30 ABS 2
2
30A ABS Control Module, ESP Control Module, Multipurpose Check Connector
F33
POWER OUT-
LET 1
POWER
OUTLET
1
40A RLY.14
F34
BACK UP
LAMP
B/UP
LAMP
10A Back-Up Lamp Switch
To Next Page
