Maintenance

387

AIR CLEANER

G160100AEN

Filter replacement

It must be replaced when necessary, and

should not be cleaned and reused.

1. Loosen the air cleaner cover attaching

clips and open the cover.

2. Replace the air cleaner filter.

3. Lock the cover with the cover attaching

clips.

OEN076010 OEN076011

OEN076012

OEN076013
