IBM BladeCenter HS22V 3
Standard specifications
The following table lists the standard specifications.
Table 1. Standard specifications
Components Specification
Form factor Single-wide (30 mm)
Processor (max) Intel Xeon 5500 series processors
Intel Xeon 5600 series processors
Number of
processors
1 standard / 2 maximum
Memory DIMM
sockets
18x DDR-3 VLP DIMM slots
Maximum
memory
Models with Xeon 5600 processors: 288 GB using 16 GB DIMMs (144 GB per processor)
Models with Xeon 5500 processors: 144 GB using 8 GB DIMMs (72 GB per processor)
Expansion slots One CIOv slot: 2 ports
One CFFh slot: 4 ports
Disk bays Two non-hot-swap bays supporting two solid-state drives
Maximum
internal storage
Up to 100 GB total internal storage
Network
interface
2x 1Gb Ethernet using a Broadcom 5709S onboard NIC
Some models also include a 2-port 10Gb controller installed in the CFFh slot
Some models also include a 2-port 8Gb Fibre Channel controller installed in the CIOv slot
Hot-swap
components
None
RAID support RAID-0, -1 and -1E (optional RAID-5 with battery-backed cache)
Systems
management
Unified Extensible Firmware Interface (UEFI), IBM Integrated Management Module (IMM),
Predictive Failure Analysis, optional embedded hypervisor for virtualization, IBM Systems
Director Active Energy Manager™, light path diagnostics, IBM Systems Director, and IBM
ServerGuide
Security Trusted Platform Module (TPM), Power-on password, administrator password, unattended
boot, selectable boot, unattended start mode
Operating
systems
supported
Microsoft Windows, Red Hat Enterprise Linux, SUSE Linux Enterprise, VMware, Oracle Solaris
Limited warranty Three-year customer replaceable unit, and onsite and offsite limited warranty
The IBM BladeCenter HS22V is shipped with the following items:
Documentation CD
Environmental Notices CD
Statement of Limited Warranty
Important Notices
Technical Note Flyer
