IBM BladeCenter HS22V 6
Table 5. Chassis support (detailed)
Maximum number of HS22V servers supported in each chassis
BC-E with AMM
(8677) (14 bays)
BC-H (models other than 4Tx)
(14 bays)
BC-H
(-4Tx)
(14 bays)
2900W supplies 2980W supplies** 2980W
CPU
TDP*
2000 W
power
supplies
2320 W
power
supplies
BC-S
(8886)
(6
bays)
Standard
blowers
Enhanced
blowers†
Standard
blowers
Enhanced
blowers†
Enhanced
blowers†
BC-HT
AC
(8750)
(12
bays)
BC-HT
DC
(8740)
(12 bays)
130W None‡ None‡ 5 None‡ 12 None‡ 14 14 10 None‡
95W 11 14 6 14 14 14 14 14 12 None‡
80W 12 14 6 14 14 14 14 14 12 None‡
60W 13 14 6 14 14 14 14 14 12 None‡
40W 14 14 6 14 14 14 14 14 12 None‡
* Thermal Design Power
** IBM BladeCenter H 2980W AC Power Modules, 68Y6601 (standard in 4Tx, optional with all other BC-H chassis
models)
† IBM BladeCenter H Enhanced Cooling Modules, 68Y6650 (standard in 4Tx, optional with all other BC-H chassis
models)
‡ Not supported
Processor options
The HS22V supports the processor options listed in the following table. The server supports one or two
processors. The table also shows which server models have each processor standard. If there is no
corresponding
where-used
model for a particular processor, then this processor is only available through
Configure to Order (CTO).
Table 6. Processor options (Part 1)
Part
number
Intel Xeon processor description Models
where used
Intel Xeon 5600 Series Processors: 4-core
81Y6038 Xeon E5603 4C 1.60GHz 4MB 1066MHz 80w A5x
81Y6039 Xeon E5606 4C 2.13GHz 8MB 1066MHz 80w -
81Y6040 Xeon E5607 4C 2.26GHz 8MB 1066MHz 80w A7x
69Y0927 Xeon E5620 4C 2.40GHz 12MB 1066MHz 80w G2x
69Y0926 Xeon E5630 4C 2.53GHz 12MB 1066MHz 80w -
69Y4746 Xeon L5609 4C 1.86GHz 12MB 1066MHz 40w -
69Y4743 Xeon L5618 4C 1.86GHz 12MB 1066MHz 40w -
81Y6041 Xeon X5647 4C 2.93GHz 12MB 1066MHz 130w B5x
81Y6043 Xeon X5672 4C 3.20GHz 12MB 1333MHz 95w C5x
81Y6045 Xeon X5687 4C 3.60GHz 12MB 1333MHz 130w C7x
