IBM BladeCenter HS22V 7
Table 6. Processor options (Part 2)
Part
number
Intel Xeon processor description Models
where used
Intel Xeon 5600 Series Processors: 6-core
69Y4744 Xeon E5645 6C 2.40GHz 12MB 1333MHz 80w -
81Y6042 Xeon E5649 6C 2.53GHz 12MB 1333MHz 80w B6x
69Y4745 Xeon L5638 6C 2.0GHz 12MB 1333MHz 60w -
69Y0928 Xeon L5640 6C 2.26GHz 12M 1333MHz 60w N2x
69Y0924 Xeon X5650 6C 2.66GHz 12M 1333MHz 95w H2x, HAx
69Y0923 Xeon X5660 6C 2.80GHz 12MB 1333MHz 95w HXx
69Y0922 Xeon X5670 6C 2.93GHz 12MB 1333MHz 95w H4x
81Y6044 Xeon X5675 6C 3.06GHz 12MB 1333MHz 95w C6x
69Y4748 Xeon X5680 6C 3.33GHz 12MB 1333MHz 130w F2x
81Y6046 Xeon X5690 6C 3.46GHz 12MB 1333MHz 130w C8x
Intel Xeon 5500 Series Processors: 4-core
49Y5151 Xeon E5506 4C 2.13GHz 4MB 800MHz 80w -
49Y5163 Xeon E5540 4C 2.53GHz 8MB 1066MHz 80w B4x
49Y5172 Xeon X5570 4C 2.93GHz 8MB 1333MHz 95w C4x
Memory options
The HS22V blade server has 18 DIMM slots. When one processor is installed, then only nine DIMM slots
can be used. When two processors are installed, then all 18 DIMM slots can be used. However, the
maximum amount of DIMMs that can be installed is also limited by the type and rank of DIMM used, as
follows:
Up to 18 single-rank RDIMMs (nine per processor) for a maximum of 72 GB (18x 4 GB)
Up to 18 dual-rank RDIMMs (nine per processor) for a maximum of 288 GB (18x 16 GB) for Xeon
5600 series and 144 GB (18x 8 GB) for Xeon 5500 series
Each CPU has three memory channels, and there are three DIMMs per channel. RDIMMs can be
populated three per channel. Maximum memory speed is limited by memory speed supported by the
specific CPU (that is, if the CPU supports only 1066 MHz, then the memory speed cannot exceed 1066
MHz in any case), and by the number and type of DIMMs installed (whatever is lower), as follows:
Intel Xeon 5600 series processors:
1333 MHz when one or two single-rank or dual-rank RDIMMs per channel are installed
800 MHz when three single-rank or dual-rank RDIMMs per channel are installed
