Failing Item Description Document Description
IDPART Vital Product Data Parts Problem Analysis; Symbolic FRU Isolation
MAPPWR MAP Power Problem Problem Analysis; Symbolic FRU Isolation
PGDPART Power Good Part Problem Analysis; Symbolic FRU Isolation
PWROC Power Supply overcurrent Problem Analysis; Symbolic FRU Isolation
PWRREG Regulator. Problem Analysis; Symbolic FRU Isolation
PWRSPLY Power Supply Problem Analysis; Symbolic FRU Isolation
SVCPROC Service Processor Card Problem Analysis; Symbolic FRU Isolation
TWRCARD Card enclosure or backplane Problem Analysis; Symbolic FRU Isolation
UPSUNIT UPS unit part Problem Analysis; Symbolic FRU Isolation
VPDPART VPD Communication Part Problem Analysis; Symbolic FRU Isolation
Table 5. SPCN failing items for Models 870 and 890 with table identifier A0:
Failing Item Description Document Description
BPCPWR Power Controller Part Problem Analysis; Symbolic FRU Isolation
BPDPWR Power Distribution Part Problem Analysis; Symbolic FRU Isolation
BPFPWR Fan and Blower assemblies Problem Analysis; Symbolic FRU Isolation
BPRPWR Power Regulator Part Problem Analysis; Symbolic FRU Isolation
IBFPWR Battery Power Unit Problem Analysis; Symbolic FRU Isolation
MAPPWR MAP Power Problem Problem Analysis; Symbolic FRU Isolation
UPSUNIT UPS unit part Problem Analysis; Symbolic FRU Isolation
Table 6. SPCN failing items for Models 870 and 890 with table identifier B0:
Failing Item Description Document Description
CBLPWR Cable Unit Part Problem Analysis; Symbolic FRU Isolation
DCAPWR DC Converter Assembly Problem Analysis; Symbolic FRU Isolation
MAPPWR MAP Power Problem Problem Analysis; Symbolic FRU Isolation
MDAPWR Fan and Blower Drive Assembly Problem Analysis; Symbolic FRU Isolation
MSAPWR Fan and Blower assemblies Problem Analysis; Symbolic FRU Isolation
OCPWR Power Supply overcurrent Problem Analysis; Symbolic FRU Isolation
(2105) Disk Unit Reference Codes
1. If the error is reported on the control panel, the unit reference code is
characters 5 through 8 of the top 16 character line of function 11. If the error is
reported on the console, the unit reference code is the 4 rightmost characters of
word 1.
2. Find the unit reference code in the following table.
For more on the Failing Item column entries, see Table 2. Disk Unit Failing Items
Details, which follows the reference code table below.
Table 1. (2105) Disk Unit Reference Codes
1xxx
System Reference Codes 137
