IBM iSeries 820 Analyze Hardware Problems (System Reference Codes

Failing Item Description Document Description
IOP I/O processor card Problem Analysis; Symbolic FRU Isolation
OPT_CLN Fiber optic cleaning kit Problem Analysis; Symbolic FRU Isolation
SVCDOCS Customer engineer directed to system problem
analysis
Problem Analysis; Symbolic FRU Isolation
(283C, 283D, 283F, 28B9, 28BC, 28CB, 28CC, 28CD, 5306) Device
Backplane Reference Codes
1. If the error is reported on the control panel, the unit reference code is
characters 5 through 8 of the top 16 character line of function 11. If the error is
reported on the console, the unit reference code is the 4 rightmost characters of
word 1.
2. Find the unit reference code in the following table.
Attention: The 673x is a read cache. Perform all actions required for 673x as a
disk drive and logic card except where separate 673x cache instructions are
provided.
For more on the Failing Item column entries, see Table 2. Device Backplane Failing
Items Details, which follows the reference code table below.
Table 1. (283C, 283D, 283F, 28B9, 28BC, 28CB, 28CC, 28CD, 5306) Device
Backplane Reference Codes
Reference Code Description/Action Perform all actions before exchanging Failing Items Failing Item
3002 Addressed device backplane failed to respond to selection DEVBPLN
STORIOA
FI01140
FI01106
3109 I/O adapter timed out a device backplane command DEVBPLN
STORIOA
FI01140
FI01106
8401 Removable media power fault DEVBPLN
FFF4 Device backplane problem DEVBPLN
STORIOA
FI01140
FI01106
Table 2. Device Backplane Failing Items Details
Failing Item Description Document Description
BACKPLN Card enclosure or backplane Problem Analysis; Symbolic FRU Isolation
CMPRES1 Compressed device and compression IOA are
not compatible
Problem Analysis; Symbolic FRU Isolation
DEVBPLN Device backplane Problem Analysis; Symbolic FRU Isolation
DEVTERM Device terminator Problem Analysis; Symbolic FRU Isolation
DISKDRV Disk drive and logic card Problem Analysis; Symbolic FRU Isolation
STORIOA Storage I/O adapter Problem Analysis; Symbolic FRU Isolation
2765, 2766, 2787, 5704
156
iSeries: iSeries 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Analyze Hardware Problems (System Reference
Codes)
