• UART Mode Select (IrDA): This field enables you to select the infrared
communication protocol-Normal (default), IrDA, or ASKIR.
• UR2 Duplex Mode (Full): This field is available when UART Mode is set
to either ASKIR or IrDA. This item enables you to determine the infrared
function of the onboard infrared chip. The options are Full and Half (de-
fault). Full-duplex means that you can transmit and send information simul-
taneously. Half-duplex is the transmission of data in both directions, but
only one direction at a time.
Onboard Parallel Port
This option is used to assign the I/O address and interrupt request (IRQ) for the
onboard parallel port.
Parallel Port Mode
Enables you to set the data transfer protocol for your parallel port. There are four
options: SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Ex-
tended Capabilities Port) and ECP+EPP.
SPP allows data output only. Extended Capabilities Port (ECP) and Enhanced
Parallel Port (EPP) are bi-directional modes, allowing both data input and output.
ECP and EPP modes are only supported with EPP- and ECP-aware peripherals.
ECP Mode Use DMA
When the onboard parallel port is set to ECP mode, the parallel port can use DMA
3 or DMA 1.
Power Management Setup PagePower Management Setup Page
Power Management Setup PagePower Management Setup Page
Power Management Setup Page
This option lets you control system power management. The system has various
power-saving modes including powering down the hard disk, turning off the
video, suspending to RAM, and software power down that allows the system to
be automatically resumed by certain events.
Phonex-AwardBIOS CMOS Setup Utility
Power Management Setup
Help Item
Menu Level
f
ACPI function [Enabled]
ACPI Enhanced Efficiency [Enabled]
HDD Power Down [Disabled]
Suspend Mode [Disabled]
Video Off Option [Suspend -> Off]
Video Off Method [V/H SYNC + Blank]
MODEM Use IRQ [3]
Soft-Off by PWRBTN [Instant-Off]
Run VGABIOS if S3 Resume [Auto]
Power on After Power Fail [Off]
IRQ/Event Activity Detect [Press Enter]
f
: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help
F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
To Next Page
