6 IBM Power 720 and 740 Technical Overview and Introduction
1.3 Physical package
The Power 720 is available in both rack-mount and tower form factors. The Power 740 is
available in rack-mount form factor only. The major physical attributes for each are discussed
in the following sections.
1.3.1 Tower model
The Power 720 can be configured as tower models by selecting the features in Table 1-2.
Table 1-2 Features for selecting tower models
Table 1-3 shows the physical dimensions of the tower models.
Table 1-3 Physical dimensions of the Power 720 tower chassis
1.3.2 Rack-mount model
The Power 720 and Power 740 can be configured as 4U (4 EIA) rack-mount models by
selecting the features shown in Table 1-4.
Table 1-4 Features for selecting rack-mount models
Cover set Power 720 (8202-E4D)
IBM Tower Cover Set FC 7567
OEM Tower Cover Set FC 7568
Dimension Power 720 (8202-E4D)
Width without tip plate 183 mm (7.2 in)
Width with tip plate 328.5 mm (12.9 in)
Depth 688 mm (27.1 in)
Height 541 mm (21.3 in)
Weight without tip plate 53.7 kg (118.1 lb)
Weight with tip plate 57.2 kg (125.8 lb)
Cover set Power 720
(8202-E4D)
Power 740
(8205-E6D)
IBM Rack-mount Drawer Bezel and Hardware FC 7134 FC 7131
OEM Rack-mount Drawer Bezel and Hardware FC 7135 FC 7132
