Installing a CD-RW/DVD drive

To install the replacement CD-RW/DVD drive, complete the following steps.

CD/DVD drive

Release tab

1. Follow the instructions that come with the drive to set any jumpers or switches.

Alignment pins

Drive retention clip

2. Attach the drive-retention clip to the side of the drive.

3. Slide the drive into the CD/DVD drive bay until the drive clicks into place.

4. Install the cover (see “Installing the cover” on page 91).

5. Slide the server into the rack.

6. Reconnect the external cables; then, reconnect the power cords and turn on the

peripheral devices and the server.

Removing an optional tape drive

To remove a tape drive from the server, complete the following steps. The following

illustration shows removing a tape drive from a 3.5-inch server model.

108 IBM System x3650 Type 7979 and 1914: Problem Determination and Service Guide
