Icom IC-208H Service Manual

[MAIN UNIT][VCO UNIT]
C124 4030006980 S.CERAMIC C1608 CH 1H 070D-T T
C125 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C126 4030006950 S.CERAMIC C1608 CH 1H 040C-T T
C127 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C128 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C129 4030009510 S.CERAMIC C1608 CH 1H 010B-T T
C130 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C131 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C132 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T T
C133 4030006950 S.CERAMIC C1608 CH 1H 040C-T T
C134 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C135 4030006950 S.CERAMIC C1608 CH 1H 040C-T T
C136 4550000540 S.TANTALUM TESVA 1V 154M1-8L B
C137 4550000530 S.TANTALUM TESVA 1V 104M1-8L B
C138 4030006930 S.CERAMIC C1608 CH 1H 020C-T B
J1 6910006810 CONNECTOR IMSA-9210B-1-10Z204-T B
J2 6910006810 CONNECTOR IMSA-9210B-1-10Z204-T B
W1 7030003860 S.JUMPER ERJ3GE JPW V except [USA] T
W2 7030003860 S.JUMPER ERJ3GE JPW V except [USA] B
EP1 0910056492 PCB B 5947B
IC1 1140005990 S.IC MB15A02PFV1-G-BND-ER T
IC2 1140005990 S.IC MB15A02PFV1-G-BND-ER T
IC3 1110005340 S.IC NJM12902V-TE1 B
IC4 1190000350 S.IC M62363FP-650C B
IC5 1130006220 S.IC TC4W53FU (TE12L) B
IC6 1130004200 S.IC TC4S66F (TE85R) T
IC7 1130004200 S.IC TC4S66F (TE85R) T
IC8 1110003200 S.IC TA31136FN (EL) B
IC9 1130006220 S.IC TC4W53FU (TE12L) T
IC10 1130006220 S.IC TC4W53FU (TE12L) T
IC11 1110004310 S.IC M62352GP 75EC T
IC12 1110005230 S.IC µPC2757TB-E3 T
IC13 1150002160 IC S-AV32 (I2) B
IC14 1150002120 IC S-AU82L (I) B
IC15 1110004050 S.IC NJM3404AV-TE1 B
IC501 1140009240 S.IC HN58X24128FPI T
IC502 1110005780 S.IC S-80945CLMC-G7F-T2 B
IC503 1180001070 S.IC TA7805F (TE16L) B
IC504 1180001250 S.IC TA7808F (TE16L) B
IC505 1140011350 S.IC HD6432143SA69FA (FX-2633B)
except [USA] T
1140011360 S.IC HD6432143SA70FA (FX2633C)
[USA] only T
IC506 1130007370 S.IC TA75S558F (TE85L) T
IC507 1110002750 S.IC TA75S01F (TE85R) B
IC508 1110004490 S.IC M62429FP 700C T
IC509 1130008090 S.IC BU4066BCFV-E1 T
IC510 1110003090 IC LA4425A T
IC511 1110004050 S.IC NJM3404AV-TE1 T
Q1 1590003290 S.TRANSISTOR UN9213J-(TX) B
Q2 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q3 1590001650 S.TRANSISTOR XP4601 (TX) T
Q4 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q5 1590001190 S.TRANSISTOR XP6501-(TX) .AB T
Q6 1590002270 S.TRANSISTOR UMG9N TL T
Q7 1530002380 S.TRANSISTOR 2SC4215-Y (TE85R) B
Q8 1590002380 S.TRANSISTOR XP1115 (TX) T
Q9 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) T
Q10 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) T
Q11 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R) T
Q12 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) T
Q13 1590001190 S.TRANSISTOR XP6501-(TX) .AB B
Q14 1590001450 S.FET 2SJ144-GR (TE85R) T
S.=Surface mount
Q15 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q16 1590001190 S.TRANSISTOR XP6501-(TX) .AB B
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q18 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q19 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q20 1590003290 S.TRANSISTOR UN9213J-(TX) B
Q21 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q22 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R) T
Q23 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R) B
Q24 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q25 1590003260 S.TRANSISTOR UN911NJ-(TX) B
Q26 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q27 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q28 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q29 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q30 1530002680 S.TRANSISTOR 2SC3357-T1 B
Q31 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R) T
Q32 1580000760 S.FET 3SK299-T1 U73 T
Q33 1530002340 S.TRANSISTOR 2SC2954-T1 B
Q34 1530002680 S.TRANSISTOR 2SC3357-T1 T
Q35 1580000760 S.FET 3SK299-T1 U73 B
Q36 1530003260 S.TRANSISTOR 2SC5006-T1 T
Q37 1530003810 S.TRANSISTOR 2SC5008-T1 T
Q38 1580000760 S.FET 3SK299-T1 U73 T
Q39 1580000760 S.FET 3SK299-T1 U73 T
Q40 1530003810 S.TRANSISTOR 2SC5008-T1 T
Q41 1530003780 S.TRANSISTOR 2SC5624VH-TL T
Q42 1590003230 S.TRANSISTOR UN9113J-(TX) T
Q43 1590003250 S.TRANSISTOR UN9115J-(TX) T
Q44 1530002060 S.TRANSISTOR 2SC4081 T106 R T
Q45 1590003230 S.TRANSISTOR UN9113J-(TX) T
Q501 1520000270 S.TRANSISTOR 2SB1182 TL Q T
Q502 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q503 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) T
Q504 1590001650 S.TRANSISTOR XP4601 (TX) B
Q505 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R) T
Q506 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q507 1590003230 S.TRANSISTOR UN9113J-(TX) T
Q508 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q509 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q510 1590003270 S.TRANSISTOR UN9210J-(TX) T
Q511 1590003290 S.TRANSISTOR UN9213J-(TX) T
Q512 1530003090 S.TRANSISTOR 2SC4213-B (TE85R) T
Q513 1590003230 S.TRANSISTOR UN9113J-(TX) B
Q514 1590003290 S.TRANSISTOR UN9213J-(TX) B
Q515 1590003240 S.TRANSISTOR UN9114J-(TX) B
Q516 1590003290 S.TRANSISTOR UN9213J-(TX) B
D1 1750000770 S.VARICAP HVC376BTRF T
D2 1750000940 S.DIODE ISS400 TE61 T
D3 1750000940 S.DIODE ISS400 TE61 T
D4 1750000370 S.DIODE DA221 TL T
D5 1750000370 S.DIODE DA221 TL T
D6 1750000370 S.DIODE DA221 TL B
D7 1750000520 S.DIODE DAN222TL B
D8 1750000800 S.DIODE HVC136TRF T
D9 1750000800 S.DIODE HVC136TRF B
D10 1750000800 S.DIODE HVC136TRF T
D12 1750000520 S.DIODE DAN222TL T
D13 1750000550 S.DIODE 1SS355 TE-17 B
D14 1750000550 S.DIODE 1SS355 TE-17 T
D15 1750000800 S.DIODE HVC136TRF B
D16 1750000800 S.DIODE HVC136TRF T
D17 1750000800 S.DIODE HVC136TRF T
D18 1750000800 S.DIODE HVC136TRF T
D19 1790001240 S.DIODE MA2S728-(TX) T
D20 1790001240 S.DIODE MA2S728-(TX) T
D21 1790001240 S.DIODE MA2S728-(TX) T
D22 1750000710 S.VARICAP HVC350BTRF T
D23 1750000710 S.VARICAP HVC350BTRF T
D24 1790001260 S.DIODE MA2S077-(TX) T
D25 1750000610 S.VARICAP MA2SV0500L T
D26 1720000700 S.VARICAP 1SV305 (TPL3) T
D27 1790000980 S.DIODE MA742 (TX) B
D28 1790000980 S.DIODE MA742 (TX) T
D29 1750000710 S.VARICAP HVC350BTRF T
D30 1750000610 S.VARICAP MA2SV0500L T
D31 1720000700 S.VARICAP 1SV305 (TPL3) T
D32 1790001260 S.DIODE MA2S077-(TX) T
D33 1790000980 S.DIODE MA742 (TX) B
6 - 3
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[MAIN UNIT]
