Icom IC-7400 Service Manual

6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
W19 8900009271 CAB OPC-912A (P1,N22,L70) <TJM>
W20 8900015160 CAB OPC-916A (P1,N22,L120) <TJM>
W21 8900009271 CAB OPC-912A (P1,N22,L70) <TJM>
W22 8900009271 CAB OPC-912A (P1,N22,L70) <TJM>
W24 8900009231 CAB OPC-908A (P1,N10,L60) <TJM>
W25 8900009660 CAB OPC-964 (P=1 N=10 L=60)
W26 8900009231 CAB OPC-908A (P1,N10,L60) <TJM>
W27 8900009231 CAB OPC-908A (P1,N10,L60) <TJM>
EP1 0880000950 UNI EX-2500 #01 SENSOR
EP2 6450001230 E.O HLJ0999-01-480 2
EP3 6450001230 E.O HLJ0999-01-480 2
S.=Surface mount
[S-LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
IC101 1130013470 S.IC CD4071BNSR
IC102 1130011130 S.IC BU4030BF-E2
IC401 1110006250 S.IC NJM2360AM-TE1-#ZZZB
IC571 1130004171 S.IC TC4S01F(TE85R,F)
Q301 1530002060 S.TRA 2SC4081 T106 R
Q302 1520000651 S.TRA 2SB1201S-TL-E
Q303 1530003301 S.TRA 2SC3647S-TD-E
Q304 1530003301 S.TRA 2SC3647S-TD-E
D301 1730000591 S.ZEN RD3.0M-T2B-A B2
D402 1790001471 S.DIO SB10-05P-TD-E
D573 1750000370 S.DIO DA221 TL
L301 6180000990 COI LAL 04NA 101K
L302 6190001191 S.COI D10F-#A814AY-101K
L303 6190001181 S.COI #D818HN-1107
L401 6190001201 S.COI D10F-#A814AY-681K
L402 6190001211 S.COI D10F-#A814AY-221K
L403 6190001201 S.COI D10F-#A814AY-681K
L601 6200007031 S.COI SLF7032T-101MR45-2PF
R1 7210002890 VAR RK161221005J/RV-308
R2 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R3 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R4 7210002890 VAR RK161221005J/RV-308
R5 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R6 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R7 7210003210 VAR EVU-FLAED7B14
R8 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R9 7210003210 VAR EVU-FLAED7B14
R10 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R11 7210003210 VAR EVU-FLAED7B14
R12 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R13 7210003210 VAR EVU-FLAED7B14
R14 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R15 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R16 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R17 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R18 7030003580 S.RES ERJ3GEYJ 153 V (15K)
R101 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R102 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R103 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R104 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R105 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R106 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R107 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R108 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R111 7030003580 S.RES ERJ3GEYJ 153 V (15K)
R112 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R113 7030003580 S.RES ERJ3GEYJ 153 V (15K)
R301 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R302 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R303 7030000300 S.RES MCR10EZHJ 220 (221)
R304 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
R305 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
R306 7510001380 S.THE NTCG20 3JH 472JT
R307 7070001280 RES ERG1SJ 120 (12)
R401 7030004050 S.RES ERJ3GEYJ 1R0 V (1)
R402 7030004050 S.RES ERJ3GEYJ 1R0 V (1)
R403 7030006091 S.RES ERA3YED 822V (8.2K)
R404 7030006461 S.RES ERA3YED 152V (1.5K)
R571 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R576 7030003680 S.RES ERJ3GEYJ 104 V (100K)
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4030006880 S.CER C1608 JB 1H 472K-T
C5 4030006880 S.CER C1608 JB 1H 472K-T
C6 4030006880 S.CER C1608 JB 1H 472K-T
C7 4030006880 S.CER C1608 JB 1H 472K-T
C8 4030006880 S.CER C1608 JB 1H 472K-T
C9 4030011600 S.CER C1608 JB 1E 104K-T
C101 4030006860 S.CER C1608 JB 1H 102K-T
C102 4030006860 S.CER C1608 JB 1H 102K-T
C111 4030011600 S.CER C1608 JB 1E 104K-T
C112 4030006860 S.CER C1608 JB 1H 102K-T
C113 4030006860 S.CER C1608 JB 1H 102K-T
C114 4030006860 S.CER C1608 JB 1H 102K-T
C115 4030011600 S.CER C1608 JB 1E 104K-T
C302 4510008540 S.ELE EEE1CA100SR
C303 4510008520 S.ELE EEE1CA470SP
C304 4310001140 MYL 250 MMW 473K EF
C305 4030013860 S.CER GRM42D1X3F120JY02L(GHM1038 SL)
C306 4510008550 S.ELE EEE1HA010SR
C307 4510008540 S.ELE EEE1CA100SR
C401 4030011600 S.CER C1608 JB 1E 104K-T
C402 4510004591 ELE 16 ME 470 HC
C403 4030011600 S.CER C1608 JB 1E 104K-T
C404 4510005000 ELE 16 ME 220 HC
C405 4030011280 S.CER C1608 CH 1H 271J-T
C406 4510008830 S.ELE EEE1CA221P
