Icom IC-7400 Service Manual

7 - 5
[RF UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
RL1 6330001320 AHY103 1
J1* 6510007020 TMP-J01X-V6 1
J2* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J121* 6510007020 TMP-J01X-V6 1
J151* 6510007020 TMP-J01X-V6 1
J261 6510007900 TBP-P01X-A1 1
J262* 6510007020 TMP-J01X-V6 1
J401* 6450001491 HLJ7001-016010 (HONTAINOMI) 1
J1001* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J1601 6510009870 PD054-02M 1
J1901 6510007900 TBP-P01X-A1 1
P261 6510003240 TMP-P01X-A1 1
P1601 6510018980 PHR-2 1
P1901 6510003240 TMP-P01X-A1 1
WS1 8970023952 SX2494 1.5+0.8DB (3)/RF
(Incl. J261, 1601, 1901, P261, 1601, 1901,
W261, 262, 1651, 1652, 1951, 1952, EP2,
MP1902, 1905)
W213 7120000490 ERD25T0 1
W252 7120000490 ERD25T0 1
W254 7120000470 ERDS2T0 1
W261 9014130400 62/99/150/C24/C31 1
W262 9086700300 WIRE 8 1
W1651 9023550130 61/99/180/B11/D33 1
W1652 9086700300 WIRE 8 1
W1951 9014130400 62/99/150/C24/C31
(incl. J1901,P1901,W1952,EP2,MP1902) 1
W1952 9086700300 WIRE 8 1
EP2 6910000630 FSOH070RN 1
EP261 6910000630 FSOH070RN 1
MP1 8510000210 194 SHIELD PLATE 1
MP2 8930055981 SHIELD SPONGE (F)-1 1
MP121 8510005980 724 SHIELD CASE 1
MP122 8510005990 724 SHIELD CASE COVER 1
MP123 8510000180 117 SHIELD PLATE 1
MP124 8930014140 EARTH SPRING (D) 1
MP125 8930054521 SHIELD SPONGE (E)-1 1
MP126 8930055981 SHIELD SPONGE (F)-1 1
MP127 8930014140 EARTH SPRING (D) 1
MP128 8930058170 SHIELD SPONGE (O) 1
MP181 8510005980 724 SHIELD CASE 1
MP211 8510005150 602 SHIELD CASE 1
MP212 8510005160 602 SHIELD CASE COVER 1
MP213 8510002280 VCOSHIELD PLATE (A) (FX-15) 1
MP214 8930052271 SHIELD SPONGE (D)-1 1
MP231 8930005320 FILTER SPACER 2
MP251 8930014140 EARTH SPRING (D) 1
MP261 8510013560 2355 U-L PLATE 1
MP281 8510012400 2177 D/A CASE 1
MP282 8930057760 2494 RF SPRING 1
MP301 8510000210 194 SHIELD PLATE 1
MP1101 8510010760 1876 DDS CASE 1
MP1102 8510010770 1876 DDS COVER 1
MP1103 8510005330 COIL CASE (SX-644) 1
MP1201 8510011511 2072 VCO CASE-1 1
MP1202 8510011521 2072 VCO COVER-1 1
MP1203 8810003961 SETSCREW (A) 2.6X5 ZC3 4
MP1204 8510011710 2072 VCO SHIELD 1
MP1205 8930013520 SPONGE (BJ) 1
MP1207 8930055981 SHIELD SPONGE (F)-1 1
MP1208 8930027891 946 EARTH SPRING-1 1
MP1301 8510010052 1691 SHIELD CASE-2 1
MP1302 8510010062 1691 SHIELD COVER-2 1
MP1303 8810003961 SETSCREW (A) 2.6X5 ZC3 3
MP1401 8510010052 1691 SHIELD CASE-2 1
MP1402 8510010062 1691 SHIELD COVER-2 1
MP1403 8810003961 SETSCREW (A) 2.6X5 ZC3 3
MP1404 8930027891 946 EARTH SPRING-1 1
MP1501 8510005980 724 SHIELD CASE 1
MP1502 8510005990 724 SHIELD CASE COVER 1
MP1601 8510005980 724 SHIELD CASE 1
MP1602 8510005990 724 SHIELD CASE COVER 1
MP1603 8930014140 EARTH SPRING (D) 1
MP1604 8930014140 EARTH SPRING (D) 1
MP1801 8510005980 724 SHIELD CASE 1
MP1802 8510005990 724 SHIELD CASE COVER 1
MP1901 8510000231 220 SHIELD CASE-1 1
MP1902 8950000180 CABLE TIE -80 2
MP1903 8930014140 EARTH SPRING (D) 1
MP1905 8950000180 CABLE TIE -80 2
[MAIN UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
RL740* 6330001320 AHY103 1
RL781* 6330000540 OMR-109F 1
CP200* 6910009670 HK3-S-T 1
CP300* 6910009670 HK3-S-T 1
CP1460* 6910009670 HK3-S-T 1
J100* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J120* 6510022601 30FMN-BMTTR-A-TBT (LF) (SN) 1
J140* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J160* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J180* 6510022591 22FMN-BMTTR-A-TBT (LF) (SN) 1
J250* 6510007020 TMP-J01X-V6 1
J400* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J700* 6450001841 TCS7568-4320177 1
J740* 6450000140 HSJ0807-01-010 1
J741* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J760* 6450000140 HSJ0807-01-010 1
J761* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J780* 6510023661 TCS4470-0141577 1
J781* 6510023671 TCS4480-0141577 1
J782* 6450001130 JPJ2042-01-110 1
J802* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J1000* 6510021651 IMSA-9180B-30B-PT1 1
J1001* 6510022811 IMSA-9180B-22B-PT1 1
J1920* 6510019191 52365-0871 1
EP2 0880000890 EX-2432 #01 1
MP200 8510000231 220 SHIELD CASE-1 1
MP791 8930014140 EARTH SPRING (D) 1
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
RL1* 6330001550 JV-12-KT 1
RL2* 6330001430 NA-12W-K 1
RL501* 6330001510 TB1-160 1
RL502* 6330001510 TB1-160 1
RL503* 6330001510 TB1-160 1
RL504* 6330001510 TB1-160 1
RL505* 6330001510 TB1-160 1
RL506* 6330001510 TB1-160 1
RL507* 6330001510 TB1-160 1
RL508* 6330001510 TB1-160 1
RL509* 6330001510 TB1-160 1
RL510* 6330001510 TB1-160 1
RL511* 6330001510 TB1-160 1
RL512* 6330001510 TB1-160 1
RL513* 6330001330 AG201344 1
RL514* 6330001330 AG201344 1
RL601* 6330001530 AE5349 (NR-HD 5V) 1
J1* 6510007020 TMP-J01X-V6 1
J5* 6510020001 52808-3071 1
J10* 6510003081 RT01T-1.0B (LF) 1
J21* 6510021531 IMSA-9230B-1-04Z024-PT1 1
J22* 6510021531 IMSA-9230B-1-04Z024-PT1 1
J23* 6510021531 IMSA-9230B-1-04Z024-PT1 1
J24* 6510021531 IMSA-9230B-1-04Z024-PT1 1
J502 6510007900 TBP-P01X-A1 1
J601 6510007900 TBP-P01X-A1 1
P501 6510003240 TMP-P01X-A1 1
P601 6510003240 TMP-P01X-A1 1
F1* 5210000061 FGB 5A PBF 1
F2* 5220000230 S-N5054 #01 1
F3* 5220000230 S-N5054 #01 1
WS1 8970022760 SX1876 J(1)/PA (Incl. W14)
WS2 8970023991 SX2494 1.5D-1 (2)/PA
(Incl. J502, P501, 602, W550, 650) 1
W1* 7030003860 ERJ3GE-JPW 1
W3* 7030003860 ERJ3GE-JPW 1
W7 7120000490 ERD25T0 1
W8 7120000490 ERD25T0 1
W14 9016910440 23/06/050/D21/W05 1
W29 9040401015 74/98/045/X98/X98 1
W504* 7030003860 ERJ3GE-JPW 1
W550 9009130242 62/99/320/C24/C31 1
W551 9086700300 WIRE 8 1
W601 7120000490 ERD25T0 1
W602 7120000490 ERD25T0 1
W650 9009130030 62/99/300/C24/C31 1
W651 9086700300 WIRE 8 1
EP2* 6910000610 FSOH050RN01 1
EP3* 6910000610 FSOH050RN01 1
EP6 6910011330 OT-009 M3 1
EP7 6910011330 OT-009 M3 1
EP650 6910000630 FSOH070RN 1
MP2 8930046570 2072 PA PLATE 1
