Icom IC-A220 Service Manual

Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
19
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[PA-B UNIT]
C515 4030007070 S.CER C1608 CH 1H 330J-T T 13.7/28.4
C516 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 17.8/24.6
C517 4030020730 S.CER GRM31A5C2J471JW01D T 23.4/23.5
C518 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 27.2/20.1
C519 4030007010 S.CER C1608 CH 1H 100D-T T 27.9/26.4
C520 4030007100 S.CER C1608 CH 1H 560J-T T 29.2/30.9
C521 4030007130 S.CER C1608 CH 1H 101J-T ATEX T 31.4/30.4
C522 4030007050 S.CER C1608 CH 1H 220J-T T 38.0/31.8
C523 4550007500 S.TAN F931D106MBABMA T 24.1/3.1
C524 4030007110 S.CER C1608 CH 1H 680J-T T 38.7/27.4
C525 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 19.8/4.2
C527 4030006900 S.CER C1608 JB 1H 103K-T ATEX T 24.1/6.2
C528 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 25.3/6.2
C529 4030007060 S.CER C1608 CH 1H 270J-T T 35.3/23.1
C531 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 25.8/12.9
C532 4030007100 S.CER C1608 CH 1H 560J-T T 37.2/20.8
C534 4030006900 S.CER C1608 JB 1H 103K-T ATEX T 21.9/13.6
C535 4550007540 S.TAN F931C155MAABMA T 50.6/7.3
C536 4030007130 S.CER C1608 CH 1H 101J-T ATEX T 28.1/17.1
C537 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 51.3/9.1
C538 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 85.7/9.9
C539 4030006880 S.CER C1608 JB 1H 472K-T T 84.3/9.9
C540 4030020730 S.CER GRM31A5C2J471JW01D T 45.9/28.5
C542 4030007140 S.CER C1608 CH 1H 121J-T T 81.0/9.9
C543 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 82.3/9.9
C544 4030020800 S.CER GRM31A5C2J680JW01D T 74.0/28.3
C545 4030006900 S.CER C1608 JB 1H 103K-T ATEX T 29.9/4.0
C547 4030021290 S.CER GQM22M5C2H220JB01L T 84.6/26.7
C548 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 29.9/2.8
C549 4030020750 S.CER GRM31A5C2J220JW01D T 94.2/29.2
C550 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 101.0/19.3
C551 4030020750 S.CER GRM31A5C2J220JW01D T 96.7/29.2
C552 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 110.1/7.2
C553 4030010780 S.CER C1608 CH 1H 1R5C-T T 99.0/24.5
C554 4030007020 S.CER C1608 CH 1H 120J-T T 99.0/21.7
C555 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 102.5/16.8
C556 4030010780 S.CER C1608 CH 1H 1R5C-T T 104.7/25.6
C557 4030007020 S.CER C1608 CH 1H 120J-T T 104.7/22.7
C558 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 104.7/19.9
C559 4030006900 S.CER C1608 JB 1H 103K-T ATEX T 108.9/7.2
C560 4030020750 S.CER GRM31A5C2J220JW01D T 106.2/30.2
C561 4030019420 S.CER GRM31A7U2J102JW31D T 108.2/9.5
C562 4030019420 S.CER GRM31A7U2J102JW31D T 110.9/27.1
C563 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 106.8/20.4
C565 4030020740 S.CER GRM31A5C2J180JW01D T 118.2/20.1
C566 4030007030 S.CER C1608 CH 1H 150J-T T 119.2/6.5
C567 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 125.8/5.4
C568 4030007130 S.CER C1608 CH 1H 101J-T ATEX T 14.9/12.7
C569 4030019420 S.CER GRM31A7U2J102JW31D T 115.4/25.2
C570 4030007070 S.CER C1608 CH 1H 330J-T T 119.2/11.0
C572 4030020750 S.CER GRM31A5C2J220JW01D T 117.4/29.1
C575 4030020740 S.CER GRM31A5C2J180JW01D T 127.9/32.6
C576 4030020740 S.CER GRM31A5C2J180JW01D T 125.8/33.6
C577 4030011100 S.CER GRM31M2C2H8R0DV01L
(GRM42-6) T 129.4/25.4
C578 4030020770 S.CER GRM31A5C2J330JW01D T 135.8/30.2
C582 4030020740 S.CER GRM31A5C2J180JW01D T 146.3/25.8
C583 4550007660 S.TAN F931E105MAABMA T 35.2/15.0
C585 4030020790 S.CER GRM31A5C2J560JW01D T 68.1/26.2
C587 4030011090 S.CER GRM31M2C2H7R0DV01L
(GRM42-6) T 110.8/19.6
C588 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 95.9/14.0
C591 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 24.5/9.0
C592 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 36.8/10.8
C595 4030007020 S.CER C1608 CH 1H 120J-T T 135.3/19.8
C596 4030007020 S.CER C1608 CH 1H 120J-T T 130.9/19.8
C597 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 133.3/17.7
C598 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 128.9/17.7
C599 4030006860 S.CER C1608 JB 1H 102K-T ATEX T 133.3/15.1
C600 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6) T 152.5/11.9
C601 4030018980 S.CER C1608 JB 1H 104K-T ATEX T 31.2/14.7
C602 4030006850 S.CER C1608 JB 1H 471K-T T 35.6/10.8
J500 6510011591 CON B2P-VH(LF)(SN)
J501 6510030790 CON SJ070010 (TMP-S01X-C1)
J502 6510023261 S.CON B6B-PH-SM4-TB(LF)(SN) T 39.6/4.2
J503 6510030790 CON SJ070010 (TMP-S01X-C1)
J504 6510030790 CON SJ070010 (TMP-S01X-C1)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
August 2015
(Amended page)
