The underlined parts have been updated from the addendum of the previous version, or from the original page.
(Amended page)
July 2019
*: Refer to “BOARD LAYOUTS” for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
[MAIN-B UNIT] (for only IC-A220)
REF
NO.
PART
NO.
DESCRIPTION QTY.
[PA-EUR UNIT] (for only IC-A210E)
REF
NO.
PART
NO.
DESCRIPTION QTY.
[K-CONNECT UNIT] (for IC-A210 and IC-A210E)
REF
NO.
PART
NO.
DESCRIPTION QTY.
[FRONT UNIT] (for IC-A210 and IC-A210E)
REF
NO.
PART
NO.
DESCRIPTION QTY.
REF
NO.
PART
NO.
DESCRIPTION QTY.
[CHASSIS UNIT]
[MAIN UNIT] (for IC-A210 and IC-A210E)
[PA UNIT] (for only IC-A210)
REF
NO.
PART
NO.
DESCRIPTION QTY.
REF
NO.
PART
NO.
DESCRIPTION QTY.
REF
NO.
PART
NO.
DESCRIPTION QTY.
6-2g
DS11 5060000022 UEL127B (ELW2702AA) 1
S1 2250000580 EC11EAB24C 1
S2* 2230001200 LS35J2-T 1
S3* 2230001200 LS35J2-T 1
S4* 2230001200 LS35J2-T 1
S5* 2230001200 LS35J2-T 1
S6* 2230001200 LS35J2-T 1
MP1 8930072850 SPONGE (JM) 1
MP2 8930072850 SPONGE (JM) 1
MP3 8930056800 2518 EARTH SPRING 1
J500* 6510011591 B2P-VH (LF) (SN) 1
J501* 6510017150 TMP-S01X-C1 1
J503* 6510017150 TMP-S01X-C1 1
J504* 6510017150 TMP-S01X-C1 1
MP1* 8930056800 2518 EARTH SPRING 1
MP2* 8930068080 THERMAL SHEET (AU) TC400HS-1.4 (12×34) 1
MP3 8930050152 THERMAL SHEET (K)-2 TC-200HS-1.4 (5×2) 1
MP4 8930073540 2974 PA PLATE 1
MP5* 8510012910 2270 RUG 1
J1 6510014210 BNC-BJ 1
J3* 6510011591 B2P-VH (LF) (SN) 1
J6* 6510030790 SJ070010 (TMP-S01X-C1) 1
J7* 6510031470 HSJ1650-010720 1
F1* 5210001070 0451008.MRL 1
W1* 7030014290 RJ25S0OHM 1
MP1 8510018590 2974 ANT CASE 1
MP2 8930073510 2974 K-ANT PLATE 1
MP3 8830003120 95119-90070 (HEXNUT ) 1
MP4 8110009160 2974 K-COVER 1
MP5 8810002950 BIND M3×6 SUS 2
MP43 8950000180 CABLE TIE-80 (DENNISON DS-80) [#01] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#02] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#03] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#05] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#11] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#21] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#23] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [#25] 4
8950000180 CABLE TIE-80 (DENNISON DS-80) [# 41] 5
MP45 8930069420 INSULATION SHEET (LL) [#03] 1
8930069420 INSULATION SHEET (LL) [#23] 1
MP48 8930090150 FERRITE SHEET (AP) [#03] 1
8930090150 FERRITE SHEET (AP) [#23] 1
8930090150 FERRITE SHEET (AP) [#41] 1
MP49 8930069680 FERRITE SHEET (P) [#03] 1
8930069680 FERRITE SHEET (P) [#23] 1
8930069680 FERRITE SHEET (P) [#41] 1
MP50 8930092110 MS-F SD-460×610-T0 (50×27) Only [#41] 1
MP51 8930090840 FERRITE SHEET (AU) Only [#41] 1
MP52 8810002510 FLAT M3×6 SUS Only [#41] 4
MP53 8950003640 CS-2 UL Only [#03] 2
MP54 8930094870 SHIELD SPONGE (DV) Only [#03] 1
MP55 8930094880 SHIELD SPONGE (DW) Only [#03] 1
MP61 8930094900 SHIELD SPONGE (DY) Only [#03] 1
MP62 8930094910 SHIELD SPONGE (DZ) Only [#03] 1
MP68 8930094920 SHIELD SPONGE (EA) Only [#03] 1
MP69 8930094930 SHIELD SPONGE (EB) Only [#03] 1
MP70 8930094940 SHIELD SPONGE (EC) Only [#03] 1
MP71 8930095010 SHIELD TAPE (AA) Only [#03] 1
RL1* 6330001730 AHY107 1
J1* 6510011591 B2P-VH (LF) (SN) 1
J3* 6510028210 SJ050010 (TMP-J01X-V6) 1
J8* 6510030790 SJ070010 (TMP-S01X-C1) 1
J10* 6510 011591 B2P-VH (LF) (SN) 1
S1* 2260003060 NANOSMDC016F-2 1
T4 5920000751 ST-82 (P)FL 1
MP1* 8510018070 2979 VCO CASE 1
MP7 8510018560 2974 VCO COVER 1
MP8 8930095300 SHIELD SPONGE (EJ) 1
MP10 8930027730 SPONGE (DC) 1
MP11 8930073230 RUBBER SHEET (BZ) 1
R1 7210003270 TP76N00NA-26F-10KB-2974 1
[VOLUME UNIT] (for IC-A210 and IC-A210E)
J500* 6510011591 B2P-VH (LF) (SN) 1
J501* 6510030790 SJ070010 (TMP-S01X-C1) 1
J503* 6510030790 SJ070010 (TMP-S01X-C1) 1
J504* 6510030790 SJ070010 (TMP-S01X-C1) 1
MP1* 8930056800 2518 EARTH SPRING 1
MP2* 8930068080 THERMAL SHEET (AU) TC400HS-1.4 (12×34) 1
MP3 8930050152 THERMAL SHEET (K)-2 TC-200HS-1.4 (5×2) 1
MP4 8930073540 2974 PA PLATE 1
MP5* 8510012910 2270 RUG 1
J1* 6510011591 B2P-VH (LF) (SN) 1
J3* 6510028210 SJ050010 (TMP-J01X-V6) 1
J8* 6510030790 SJ070010 (TMP-S01X-C1) 1
J10* 6510011591 B2P-VH (LF) (SN) 1
S1* 2260003060 NANOSMDC016F-2 1
T4 5920000751 ST-82 (P) FL 1
MP1 8510018070 2979 VCO CASE 1
MP7 8510018560 2974 VCO COVER 1
MP8 8930095300 SHIELD SPONGE (EJ) 1
MP10 8930027730 SPONGE (DC) 1
MP11 8930073230 RUBBER SHEET (BZ) 1
To Next Page
