Icom IC-A25N User Manual

1
ACCESSORIES ATTACHMENTS
1-3
Attaching accessories
D Antenna
Connect the supplied antenna to the antenna
connector.
D Battery pack/Battery case
To attach:
1. Slide the battery pack in the direction of the arrow.
(q)
2. Push the battery pack until the battery sliding
locks make a ‘click’ sound. (w)
To detach:
1. Push both battery sliding locks in the direction of
the arrow. (z)
• The battery pack is then released.
2. Lift up to detach the battery pack. (x)
CAUTION:
• DO NOT carry the transceiver by holding only the
antenna.
• DO NOT connect an antenna other than supplied
antenna or those listed in this manual.
• Transmitting without an antenna may damage the
transceiver.
CAUTION: DO NOT attach or detach the battery
pack or the battery case when the transceiver is wet
or soiled. This may result in water or dust getting into
the transceiver, battery pack, or battery case and
may damage the transceiver.
NOTE: Keep the battery pack terminals clean. It’s a
good idea to occasionally clean them.
z
x
z
q
w
Battery pack
Battery sliding locks

Icom IC-A25N Specifications

General

Display type	LCD
Display diagonal	2.3 \
Backlight display	Yes
Battery type	BP-288
Battery life (max)	10.5 h
Number of batteries supported	1
Product color	Black, Grey
International Protection (IP) code	IP57
Operating temperature (T-T)	-10 - 60 °C
Antenna connector type	BNC
Purpose	Aviation Service (Air Band)
Maximum range	- m
Operating frequency	108 - 163.275 MHz

Weight and Dimensions

Depth	31.8 mm
Width	58.9 mm
Height	148.4 mm
Weight	340 g
