Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
1
SECTION 6
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
IC2 1110002751 S.IC TA75S01F(TE85RF) T 68.9/21.0
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 38.3/35.7
IC5 1110005340 S.IC NJM12902V-TE1-#ZZZB T 29.7/11.6
IC6 1110005320 S.IC NJM13403V-TE1-#ZZZB T 16.0/34.6
IC7 1110005340 S.IC NJM12902V-TE1-#ZZZB T 29.9/34.6
IC8 1190000350 S.IC M62363FP-650C T 40.3/15.2
IC9 1110005350 S.IC NJM2870F05-TE1-#FZZB B 84.2/14.2
IC10 1130011770 S.IC CD4066BPWR T 22.9/34.6
IC12 1110007850 S.IC TA7368PL-R10-R <SLVJ> T 89.6/13.6
IC13 1140012721 S.IC HD6433687C73FPV(FX-2775A-1) T 12.5/14.4
IC14 1110006260 S.IC BD5242G-TR T 6.6/5.9
IC15 1130011540 S.IC BR24L16FV-WE2 B 16.0/11.6
Q1 1560000841 S.FET 2SK1829(TE85RF) T 75.0/39.5
Q2 1580000731 S.FET 3SK293(TE85LF) B 77.8/37.9
Q3 1580000800 S.FET 3SK324UG-TL-E B 66.2/37.9
Q4 1530003311 S.TRA 2SC5107-O(TE85RF) B 51.4/23.1
Q6 1590003231 S.TRA UNR9113G0L T 71.7/19.1
Q7 1560001232 S.FET RD07MVS2-T112 T 82.6/27.1
Q8 1560001241 S.FET RD01MUS1-T113 T 76.1/27.6
Q9 1530003421 S.TRA 2SC5110-O(TE85RF) T 70.7/34.4
Q10 1530003311 S.TRA 2SC5107-O(TE85RF) T 59.4/36.3
Q11 1530003311 S.TRA 2SC5107-O(TE85RF) B 56.8/36.4
Q12 1530003311 S.TRA 2SC5107-O(TE85RF) T 59.1/31.6
Q13 1530002921 S.TRA 2SC4226-T1 Y25 (R25) T 54.1/32.3
Q14 1530002921 S.TRA 2SC4226-T1 Y25 (R25) T 54.1/34.8
Q15 1590001400 S.TRA XP1214(TX) B 56.5/32.6
Q16 1590003291 S.TRA UNR9213G0L B 59.1/32.6
Q17 1530002851 S.TRA 2SC4116-BL(TE85RF) T 55.5/44.1
Q18 1560000541 S.FET 2SK880-Y(T5RICOMF) B 51.5/39.2
Q19 1530002851 S.TRA 2SC4116-BL(TE85RF) T 43.3/29.9
Q20 1560001360 S.FET 2SK3019 TL T 27.7/29.4
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q21 1510000920 S.TRA 2SA1577 T106 Q T 71.9/16.4
Q22 1510000920 S.TRA 2SA1577 T106 Q T 24.9/25.9
Q23 1520000460 S.TRA 2SB1132 T100 R T 81.1/15.1
Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ>
Q24 1590001190 S.TRA XP6501-(TX).AB T 76.5/15.1
Q25 1590003231 S.TRA UNR9113G0L T 75.7/11.7
Q26 1590003291 S.TRA UNR9213G0L T 49.6/18.4
Q27 1590003291 S.TRA UNR9213G0L T 24.8/16.7
Q28 1590003431 S.TRA UNR911HG0L B 63.8/10.8
Q29 1590003271 S.TRA UNR9210G0L B 36.1/9.4
Q30 1510001080 S.TRA 2SA2048 TLR T 91.9/8.5
Eqv. 1520000920 S.TRA 2SB1691WL-TL-E
Q31 1590001190 S.TRA XP6501-(TX).AB T 91.4/5.2
Q32 1590003020 S.TRA XP4216-(TX) T 16.5/23.5
Q33 1590003231 S.TRA UNR9113G0L T 19.9/22.6
Q34 1560001360 S.FET 2SK3019 TL T 11.6/31.9
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q35 1560001360 S.FET 2SK3019 TL T 9.5/30.5
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q39 1530004140 S.TRA L2SC4081RT1G <SLVJ> B 39.1/42.7
Q40 1510001151 S.TRA L2SA1576AST1G <SLVJ> B 39.1/40.0
Q41 1590003291 S.TRA UNR9213G0L [F] B 59.7/11.9
1590003291 S.TRA UNR9213G0L [P]
Q42 1590003291 S.TRA UNR9213G0L [F] T 12.8/24.4
1590003291 S.TRA UNR9213G0L [P]
D1 1790001790 S.DIO RB876W TL B 93.6/17.6
D2 1750000581 S.DIO 1SV307(TPH3F) B 91.5/31.1
D4 1750000721 S.VAR HVC375BTRF-E B 80.3/33.4
D5 1750000581 S.DIO 1SV307(TPH3F) B 87.6/33.4
D6 1790001261 S.DIO MA2S077G0L B 86.7/35.9
D8 1750000721 S.VAR HVC375BTRF-E B 83.0/33.4
D9 1750000711 S.VAR HVC350BTRF-E B 73.6/37.7
D10 1750000711 S.VAR HVC350BTRF-E B 72.3/37.7
D14 1790001261 S.DIO MA2S077G0L T 65.8/35.3
D15 1790001261 S.DIO MA2S077G0L T 65.8/36.7
D16 1750000771 S.VAR HVC376BTRF-E T 55.1/28.8
D17 1750000771 S.VAR HVC376BTRF-E T 53.7/28.8
D18 1720000471 S.VAR 1SV239(TPH3F) B 49.6/28.2
D19 1750000771 S.VAR HVC376BTRF-E T 53.6/37.8
D20 1750000771 S.VAR HVC376BTRF-E T 50.9/37.5
D21 1750000721 S.VAR HVC375BTRF-E T 49.2/31.5
D22 1750000721 S.VAR HVC375BTRF-E T 49.2/34.9
D23 1790001251 S.DIO MA2S1110GL T 70.5/40.4
D24 1790001251 S.DIO MA2S1110GL T 41.5/39.2
D26 1790001790 S.DIO RB876W TL B 36.1/7.3
D27 1750001850 S.DIO LDAN222T1G <SLVJ> B 21.3/6.5
D28 1790001261 S.DIO MA2S077G0L B 8.5/11.2
D29 1750001810 S.DIO L1SS400T1G <SLVJ> B 21.5/4.2
D30 1790001261 S.DIO MA2S077G0L T 28.6/42.4
FI1 2030000150 S.MON DSF753SB 46.350 MHz (FL-335) B 62.7/27.1
FI2 2020002410 CER LTM450FW <JJE>
X2 6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz T 36.9/28.9
X3 6050011720 S.XTA CR-764 SMD-49TB 19.6608 MHz
<KDS> B 12.0/5.9
MODEL VERSION
SYMBOL
IC-F14
USA-02 [A]
GEN-02 [C]
USA-03 [D]
USA-04 [H]
IC-F15
EUR-02 [B]
IC-F16
RUS-02 [E]
RUS-05 [F]
CHN-02 [G]
RUS-03 [P]
IC-F14S
USA-02 [I]
GEN-02 [K]
USA-03 [L]
IC-F15S
EUR-02 [J]
IC-F16S
RUS-02 [M]
RUS-05 [N]
IC-F3018
CHN-01 [O]
To Next Page
