[FRONT-A UNIT] (for IC-F2700 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C76 4030018860 S.CER ECJ0EB0J105K B 24.7/11.1
C77 4030017420 S.CER ECJ0EC1H470J B 82.2/35.1
C78 4030017420 S.CER ECJ0EC1H470J B 81/32.4
C79 4030016930 S.CER ECJ0EB1A104K B 28.2/11.1
J1 6510024520 S.CNR 12FLT-SM1-TB B 91.2/8.5
J2 6450002210 CNR 3017-8821 <KIN>
J4 6510022020 S.CNR 14FLT-SM1-TB B 56.6/24.8
DS1 5030002810 LCD L4-0013TVY-1
DS5 5040002310 S.LED SML-311YTT86 T 49.9/6.5
DS6 5040002310 S.LED SML-311YTT86 T 35.4/6.5
DS7 5040002310 S.LED SML-311YTT86 T 20.9/6.5
DS8 5040002310 S.LED SML-311YTT86 T 93.4/6.5
DS9 5040002310 S.LED SML-311YTT86 T 78.9/6.5
DS11 5040002310 S.LED SML-311YTT86 T 82.1/27
DS12 5040002310 S.LED SML-311YTT86 T 72.1/27
DS13 5040002310 S.LED SML-311YTT86 T 62.1/27
DS14 5040002310 S.LED SML-311YTT86 T 52.1/27
DS15 5040002310 S.LED SML-311YTT86 T 42.1/27
DS16 5040002310 S.LED SML-311YTT86 T 32.1/27
DS17 5040002930 S.LED SML-512MW T86 T 105.6/14
DS18 5040002990 S.LED SML-512UWT86 T 97.6/14
DS26 5040002310 S.LED SML-311YTT86 T 64.4/6.5
S9 2250000511 ECR RH70N1037E20-13F-2781
SP1 2510001290 SP C062SB504-11
W1 8900013690 CBL OPC-1425 (N=12, L=92)
W2 8900013700 CBL OPC-1426
EP1 8930065150 LCT SRCN-2781-SP-N-W
[FRONT-B UNIT] (for IC-F2800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R8 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 83.8/20.8
R9 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 56.2/21.1
R12 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.2/29.6
R14 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 65/32
R15 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.5/27.2
R16 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 62.3/33
R18 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 64/25.2
R19 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 70/11.3
R20 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 21/14.5
R21 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 23.2/30.8
R22 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 71/12.3
R24 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 31/17.9
R25 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 29.2/11.1
R26 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 27.5/16.5
R28 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 29.2/12
R29 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 29.4/17.9
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 17.2/16.2
R31 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 12.2/21.6
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.7/20.3
R33 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 104.3/34.6
R34 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 121.2/29.9
R35 7210003050 VAR EVU-F2KFK3 B14 (10KB)
R36 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 99.2/28.8
R37 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 99.2/29.8
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 87.2/11.7
R39 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 92.3/13.7
R40 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 54.5/6.9
R41 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 57.5/8.9
R42 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 63.4/7.8
R43 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 100.3/12.6
R44 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 107.6/12.5
R48 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 77.6/29.4
R49 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 78.5/29.6
R50 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 79.4/29.9
R51 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 80.3/30.2
R52 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 81.2/29.9
R55 7510001470 S.TMR NTCG20 4AG 473JT B 85/25.3
R56 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 83.6/26.7
R57 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 60.7/33.2
R58 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 56.9/29.8
R59 7310005130 S.TRI RH03ADCS5X (470 k
Ω
) B 57.7/32.2
R60 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 7.2/9
R61 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 5.7/3.9
R62 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 26/10.1
R63 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 31.2/4.3
R64 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 29.2/10.1
R65 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 30.5/9.1
R66 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 32.5/9.1
R67 7030009280 S.RES ERJ2GE 331 X (330
Ω
) B 27.6/9.1
R68 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 29.2/9.1
R70 7410001130 S.ARY EXB28V102JX B 67.9/19.9
R71 7410001130 S.ARY EXB28V102JX B 68.3/17
R72 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 86.5/27.6
R73 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 23.2/29.9
R74 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 17.2/14.1
R75 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 53.8/23.4
R76 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 75.8/30.1
R77 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 4.7/3.9
R80 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 121.9/11.6
R81 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 67.8/4.3
R82 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 53.7/4.8
R83 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 99.2/26.2
R84 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 99.2/25.2
C10 4030016930 S.CER ECJ0EB1A104K B 84.4/19
C11 4030017030 S.CER ECJ0EB1A273K B 85.2/32
C12 4030017630 S.CER ECJ0EC1H120J B 86.1/21.8
C13 4030017580 S.CER ECJ0EC1H060C B 86.1/19.9
C14 4030017640 S.CER ECJ0EB1H150J B 86.1/18.1
C15 4030016930 S.CER ECJ0EB1A104K B 83.7/13.4
C16 4030016790 S.CER ECJ0EB1C103K B 85.4/23.6
C17 4030016930 S.CER ECJ0EB1A104K B 83.8/23.3
C18 4030017420 S.CER ECJ0EC1H470J B 103.4/8.8
C28 4030017460 S.CER ECJ0EB1E102K B 62.7/26
C30 4030016930 S.CER ECJ0EB1A104K B 82.7/8
C31 4030017460 S.CER ECJ0EB1E102K B 92.5/4.2
C33 4030017460 S.CER ECJ0EB1E102K B 11.3/21.6
C35 4030017420 S.CER ECJ0EC1H470J B 92.5/5.1
C36 4030017460 S.CER ECJ0EB1E102K B 24.8/29.9
C37 4030017420 S.CER ECJ0EC1H470J B 6.2/9
C38 4030017420 S.CER ECJ0EC1H470J B 88.7/11.2
C39 4030017460 S.CER ECJ0EB1E102K B 96/10.5
C41 4030017420 S.CER ECJ0EC1H470J B 93.9/11.3
C42 4030017420 S.CER ECJ0EC1H470J B 13.3/25
C43 4030017460 S.CER ECJ0EB1E102K B 26.7/15.1
C44 4030017420 S.CER ECJ0EC1H470J B 90.5/11.2
C45 4030018860 S.CER ECJ0EB0J105K B 8.2/9
C46 4030017420 S.CER ECJ0EC1H470J B 94.7/12.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 2
[FRONT-B UNIT] (for IC-F2800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 B 84.7/29.8
IC3 1140010770 S.IC HD64F3687FP B 69.6/14.8
IC4 1130005720 S.IC TC7W04F (TE12L) B 65.8/28.7
IC5 1130008560 S.IC TC75S51F (TE85L) B 29.7/15.7
IC6 1110005350 S.IC NJM2870F05-TE1 B 81.4/5.4
IC7 1130009120 S.IC SED1526F0A B 43.3/21.1
IC8 1130005640 S.IC TC4W53F (TE12L) B 9.2/5.5
IC9 1110005310 S.IC AN6123MS B 29.7/6.5
Q1 1590001330 S.TR DTA114EUA T106 B 62.6/34.9
Q2 1590000680 S.TR DTC114EUA T106 B 66.6/24.2
Q3 1530002850 S.TR 2SC4116-BL (TE85R) B 70.4/8.9
Q4 1590001050 S.TR DTC114TUA T106 B 73.3/8.9
Q5 1590001050 S.TR DTC114TUA T106 B 72.8/11.4
Q6 1590001050 S.TR DTC114TUA T106 B 103/12.1
Q7 1590001050 S.TR DTC114TUA T106 B 105.6/12.1
D1 1790000620 S.DIO MA77 (TX) B 84.9/15.3
D4 1790001250 S.DIO MA2S111-(TX) B 62.7/31.3
D5 1790000950 S.ZEN MA8056-M (TX) B 24/28.5
D6 1790000950 S.ZEN MA8056-M (TX) B 24/32.2
D7 1790000950 S.ZEN MA8056-M (TX) B 19.9/15.6
D8 1750000550 S.DIO 1SS355 TE-17 B 89.4/12.6
D9 1750000130 S.DIO DA204U T106 B 61.8/9.9
D10 1750000130 S.DIO DA204U T106 B 59.2/9.9
D11 1750000130 S.DIO DA204U T106 B 55/9.3
D12 1790001250 S.DIO MA2S111-(TX) B 72.3/29.5
X1 6050011720 S.XTL CR-764 (19.6608 MHz) B 89.3/20.5
L1 6200003640 S.COL MLF1608E 100K-T B 10.1/8.9
R4 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 86.1/13.4
R5 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 85.6/16.7
R6 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 85.1/20.8
R7 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 83.8/17
To Next Page
