[FRONT-B UNIT] (for IC-F2800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C47 4030017420 S.CER ECJ0EC1H470J B 18.5/15.8
C48 4030017460 S.CER ECJ0EB1E102K B 31.8/15.3
C49 4030016790 S.CER ECJ0EB1C103K B 27.8/17.7
C50 4550006540 S.TAN ECST1CY475R B 27.5/20.8
C51 4030017460 S.CER ECJ0EB1E102K B 11.7/19.3
C52 4030017420 S.CER ECJ0EC1H470J B 26.9/12
C53 4030004760 S.CER C2012 JF 1H 104Z-T B 84.1/5.8
C54 4510006120 S.ELE ECEV1ES4R7SR B 76.7/5.2
C55 4030004760 S.CER C2012 JF 1H 104Z-T B 85.9/5.8
C56 4030006900 S.CER C1608 JB 1H 103K-T B 81/7.8
C57 4550006050 S.TAN TEESVA 0J 106M8L B 84.9/10.3
C58 4030017730 S.CER ECJ0EB1E471K B 104.6/14
C59 4030017730 S.CER ECJ0EB1E471K B 102.8/14
C60 4030016930 S.CER ECJ0EB1A104K B 83.6/27.6
C61 4030016930 S.CER ECJ0EB1A104K B 55.5/34.1
C62 4030016930 S.CER ECJ0EB1A104K B 53.9/33.7
C63 4030016930 S.CER ECJ0EB1A104K B 53.9/32.8
C64 4030016930 S.CER ECJ0EB1A104K B 53.8/31.6
C65 4030016930 S.CER ECJ0EB1A104K B 54.8/31.6
C66 4030017490 S.CER C1608 JB 1A 105K-T B 54.3/26.3
C67 4030017490 S.CER C1608 JB 1A 105K-T B 54.3/24.8
C68 4030017460 S.CER ECJ0EB1E102K B 53.4/21.7
C69 4030017460 S.CER ECJ0EB1E102K B 87.3/5.2
C70 4030017460 S.CER ECJ0EB1E102K B 29.2/12.9
C71 4030017460 S.CER ECJ0EB1E102K B 12.7/4.1
C72 4510004630 S.ELE ECEV1CA100SR B 25.6/6.1
C73 4550006050 S.TAN TEESVA 0J 106M8L B 34/5.7
C74 4030016930 S.CER ECJ0EB1A104K B 27.6/10.1
C75 4030016930 S.CER ECJ0EB1A104K B 31.5/9.1
C76 4030018860 S.CER ECJ0EB0J105K B 27.6/11.1
C79 4030016930 S.CER ECJ0EB1A104K B 30.9/11.1
J1 6510024520 S.CNR 12FLT-SM1-TB B 90.9/8.5
J2 6450002210 CNR 3017-8821 <KIN>
J4 6510022020 S.CNR 14FLT-SM1-TB B 59.4/24.8
DS1 5030002810 LCD L4-0013TVY-1
DS2 5040002310 S.LED SML-311YTT86 T 104.3/22.5
DS3 5040002310 S.LED SML-311YTT86 T 104.3/34.5
DS7 5040002310 S.LED SML-311YTT86 T 23.6/6.5
DS8 5040002310 S.LED SML-311YTT86 T 123.5/30.4
DS9 5040002310 S.LED SML-311YTT86 T 139.8/30.4
DS10 5040002310 S.LED SML-311YTT86 T 156.1/30.4
DS11 5040002310 S.LED SML-311YTT86 T 84.9/27
DS12 5040002310 S.LED SML-311YTT86 T 74.9/27
DS13 5040002310 S.LED SML-311YTT86 T 64.9/27
DS14 5040002310 S.LED SML-311YTT86 T 54.9/27
DS15 5040002310 S.LED SML-311YTT86 T 44.9/27
DS16 5040002310 S.LED SML-311YTT86 T 34.9/27
DS17 5040002930 S.LED SML-512MW T86 T 108.3/14
DS18 5040002990 S.LED SML-512UWT86 T 100.3/14
DS19 5040002310 S.LED SML-311YTT86 T 123.5/10.4
DS20 5040002310 S.LED SML-311YTT86 T 139.8/10.4
DS21 5040002310 S.LED SML-311YTT86 T 156.1/10.4
DS22 5040002310 S.LED SML-311YTT86 T 67.1/6.5
DS23 5040002310 S.LED SML-311YTT86 T 81.6/6.5
DS24 5040002310 S.LED SML-311YTT86 T 52.6/6.5
DS25 5040002310 S.LED SML-311YTT86 T 38.1/6.5
DS26 5040002310 S.LED SML-311YTT86 T 96.1/6.5
W1 8900013690 CBL OPC-1425 (N=12, L=92)
EP1 8930065150 LCT SRCN-2781-SP-N-W
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110005340 S.IC NJM12902V-TE1 B 75.1/36.2
IC2 1110006220 S.IC AK2346-E2 T 48.4/27.8
IC4 1130010100 S.IC LMX2352TMX B 73.1/64.7
IC6 1130009700 S.IC LC73872M-TRM B 10.4/16.7
IC8 1190001350 S.IC M62364FP 600D B 68.7/27.4
IC9 1110005340 S.IC NJM12902V-TE1 T 114.4/51.5
IC12 1110003490 S.IC TA31136FN (D,EL) B 27.9/28.4
IC13 1110005290 S.IC NJM2115V-TE1
[F2721D], [F2821D] only T 87.6/17.2
IC15 1110006230 S.IC NJM2711F-TE1
[F2721D], [F2821D] only B 87.5/19.2
IC16 1190002080 S.IC AD7476ARTZ-500RL7
[F2721D], [F2821D] only B 97.7/20.7
IC17 1130008810 S.IC TC7SH32FU (TE85L)
[F2721D], [F2821D] only B 122/19.2
IC18 1130011610 S.IC AK4550VT-E2
[F2721D], [F2821D] only T 97/18.5
IC19 1110006230 S.IC NJM2711F-TE1
[F2721D], [F2821D] only B 93.1/35.3
IC20 1140011880 S.IC HD64F2239TE16
[F2721D], [F2821D] only T 111/30.5
IC21 1130011620 S.IC TC7MET374AFK (EC)
[F2721D], [F2821D] only B 122/14
IC22 1130003830 S.IC TC7S04F (TE85R)
[F2721D], [F2821D] only T 120.5/22.4
IC23 1140010190 S.IC HD64F2268TF20 B 100.3/60.1
IC24 1110005730 S.IC S-80928CNMC-G8Y-T2
[F2721D], [F2821D] only T 116/17.5
IC25 1130011600 S.IC TC7MET541AFK (EC)
[F2721D], [F2821D] only B 122/8
IC26 1140009240 S.IC HN58X24128FPI B 83/70
IC28 1130010390 S.IC HN58X2416TI
[F2721D], [F2821D] only T 93.5/27
IC29 1150002031 IC RA30H4452M-21 [H-25W]
1150002091 IC RA30H4047M-21 [L-25W]
1150002210 IC RA55H4047M [L-45W]
1150002220 IC RA55H4452M [H-45W]
IC30 1190001340 S.IC M62334FP 600C B 27.5/41.8
IC31 1180002590 S.REG XC6204B332MR
[F2721D], [F2821D] only T 109.5/11.5
IC32 1180002640 S.REG R1114N151B-TR
[F2721D], [F2821D] only T 105/11.5
IC33 1180002590 S.REG XC6204B332MR
[F2721D], [F2821D] only B 105.5/13.1
IC34 1110002750 S.IC TA75S01F (TE85R) B 148.9/38.1
IC35 1120002510 S.IC DS14C232TM T 109.1/98.4
IC36 1180001250 S.IC TA7808F (TE16L) B 120.8/75.2
IC37 1110002750 S.IC TA75S01F (TE85R) T 51.3/84.1
IC38 1110003090 IC LA4425A
IC39 1110005800 IC TA8225L
IC40 1180000970 S.IC AN78L05M-(E1) B 138.3/76.1
IC41 1140011890 S.IC TMS320VC5416PGE120
[F2721D], [F2821D] only B 111/30.5
IC42 1130008230 S.IC BU4053BCFV-E2 B 61.3/12
IC43 1130008230 S.IC BU4053BCFV-E2 B 61.3/17.7
IC44 1110002750 S.IC TA75S01F (TE85R) B 70.3/7.6
IC45 1130007570 S.IC BU4094BCFV-E2 B 128.2/57.9
IC46 1110005770 S.IC S-80942CNMC-G9C-T2 T 98.5/68.5
Q1 1530002850 S.TR 2SC4116-BL (TE85R) B 39.3/29.4
Q2 1590001330 S.TR DTA114EUA T106 B 27.6/16.2
Q3 1530002600 S.TR 2SC4215-O (TE85R)
[F2721D], [F2821D] only B 84.6/26.9
Q4 1560000530 S.FET 2SK880-GR (TE85R) B 82/53.5
Q6 1530002600 S.TR 2SC4215-O (TE85R) B 33.8/34.8
Q7 1590000430 S.TR DTC144EUA T106 T 107.8/50.6
Q9 1530002850 S.TR 2SC4116-BL (TE85R) B 71/54.5
Q10 1530002600 S.TR 2SC4215-O (TE85R) B 34.1/51.4
Q11 1530002920 S.TR 2SC4226-T1 R25 T 50.5/51.6
Q12 1530002920 S.TR 2SC4226-T1 R25 T 50.5/48.8
Q13 1560000990 S.FET PMBFJ310 B 40.2/56.2
Q14 1560000990 S.FET PMBFJ310 B 37.2/56.2
Q15 1590000720 S.TR DTA144EUA T106 T 108.6/58.5
Q16 1530002920 S.TR 2SC4226-T1 R25 T 63.4/49.1
Q17 1590001400 S.TR XP1214 (TX) B 49/50.2
Q18 1590000430 S.TR DTC144EUA T106 B 52.2/50.2
Q19 1530003310 S.TR 2SC5107-O (TE85R) B 64.2/59.1
Q20 1530003310 S.TR 2SC5107-O (TE85R) T 62.7/54.3
Q21 1530003310 S.TR 2SC5107-O (TE85R) B 50/71.4
Q22 1530003310 S.TR 2SC5107-O (TE85R) B 59.6/64.3
Q23 1530003310 S.TR 2SC5107-O (TE85R) B 62.2/92.3
Q24 1580000730 S.FET 3SK293 (TE85L) B 16.2/66.5
Q26 1560000840 S.FET 2SK1829 (TE85R) T 17/64.3
Q27 1590000430 S.TR DTC144EUA T106 B 98.7/75.9
Q28 1590000430 S.TR DTC144EUA T106 T 128.6/45.7
Q29 1590000990 S.TR DTC363EK T146 B 148/83.4
Q30 1510000920 S.TR 2SA1577 T106 Q B 101.2/75.9
Q31 1520000460 S.TR 2SB1132 T100 R T 108.5/74.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 3
