4
SETTINGS
10
[ROTARY SELECTOR]
[VOL]
[Lower]
[Upper]
You can adjust the squelch level. The squelch circuit
mutes the received audio, depending on the squelch
level setting.
Setting the squelch level
NOTE: Turn ON the Beep function before you start
setting the squelch level. (p. 6)
1. Rotate [VOL] to turn OFF the transceiver power.
2. Set [ROTARY SELECTOR] to any channel other
than Channel 16.
3. While holding down [Upper], rotate [VOL] to turn
ON the transceiver and enter the Squelch Level
Adjustment mode.
• An opening beep sounds and the selected channel
number is announced.
4. Push [Upper] to increase the squelch level (tight
squelch), or push [Lower] to decrease the squelch
level (loose squelch).
• A beep sounds after pushing [Upper] or [Lower]. An
error beep sounds if you try to exceed the adjustable
range.
L The adjustable range is 0 (loose squelch) to 9 (tight
squelch).
5. Rotate [VOL] to turn OFF the transceiver and exit
the Squelch Level Adjustment mode.
