■ Mounting the transceiver
The universal mounting bracket supplied with your transceiver
allows overhead mounting. Please read the following instruc-
tions carefully.
• Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more then 1.5 kg.
3
CONNECTION AND MAINTENANCE
11
■ Optional UT-96/UT-105 instal-
lation
The optional UT-96/UT-105 units install as follows:
q Turn power OFF, then disconnect the DC power cable.
w Unscrew the 4 screws, then remove the bottom cover.
e Install the unit as shown in the diagram below.
r Replace the bottom cover and screws, then the DC power
cable.
NOTE: The sponge supplied with the UT-105 is for the
IC-F30/F40 series transceivers only.
Flat washer
Spring washer
When using
self-tapping screws
To Next Page
