1
PANEL DESCRIPTION
5
TX CODE KEY
Select a transmit 5-tone code (station code) channel.
• Push and hold to changes the contents of the sta-
tion code using []/[]keys.
• Push to selects a TX 5-tone code channel using
[]/[]keys after pushing this key.
TX CODE CHANNEL UP/DOWN KEY
Push to selects a TX code channel directory.
DTMF CHANNEL SELECT KEY
Push this key to select a DTMF channel.
• Push this key, then select the desired DTMF chan-
nel using the []/[]keys.
Push and hold this key to transmit the selected
DTMF code.
NOTE: DTMF channels 6 and 7 are used for ID
code and emergency code respectively, depend-
ing on your system set up.
Ask your System Operator or Dealer about DTMF
channels 6 and 7 before using these.
C. TONE CHANNEL ENTER KEY
Push this key then input a continuous tone memory
channel number via the keypad to change the tone
frequency.
ID MEMORY READ KEY
Recalls detected ID codes.
• Push this key, then push []/[]for selection.
• Up to 5 ID's are memorized.
Push and hold this key to erase all memorized IDs.
LIGHT
Push to select the backlight condition.
ON :Turns ON the backlight continuously.
OFF :Turns OFF the backlight.
AUTO :Turns ON/OFF depending on the ACC
socket pin 1 voltage.
ON: Low (0 V) OFF: High (12 V)
ATTENUATOR
Push to turn the attenuator function ON/OFF.
NOTE: The attenuator function protects desired
signals from distorting when excessively strong
signals, such as broadcast, pager signals, etc.
are nearby.
TRUNKING GROUP SWITCH
Push to select the Trunking group.
