PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110003491 S.IC TA31136FNG(D,EL) T 57.8/24.7
IC2 1110002751 S.IC TA75S01F(TE85R,F) T 60/54.9
IC3 1150002371 IC RA30H1317M1-121 [EUR-01]
1150002371 IC RA30H1317M1-121 [EXP-01]
1150002420 IC RA60H1317M1A-101 [USA-01]
1150002420 IC RA60H1317M1A-101 [EXP-02]
1150002420 IC RA60H1317M1A-101 [CHN-01]
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 77.8/29.2
IC8 1110003091 IC LA4425A-E
IC9 1180003500 S.REG NJM7808DL1A-TE1-#FZZB T 123.3/45.7
IC10 1180003460 S.REG NJM2831F05-TE1-#ZZZB T 121.6/35.4
IC14 1130011770 S.IC CD4066BPWR B 35.1/16.4
IC15 1110002751 S.IC TA75S01F(TE85R,F) B 32/6.7
IC16 1110005340 S.IC NJM12902V-TE1-#ZZZB B 20.6/21.1
IC17 1130011760 S.IC CD4094BPWR B 53.1/9.9
IC18 1110007290 S.IC AK2330P-L B 35.9/25.7
IC19 1110002751 S.IC TA75S01F(TE85R,F) B 83.7/18.1
IC20 1190001340 S.IC M62334FP 600C B 72.3/26.3
Q1 1560000841 S.FET 2SK1829(TE85R,F) T 33.7/39.7
Q2 1580000731 S.FET 3SK293(TE85L,F) B 41.5/38.7
Q3 1580000800 S.FET 3SK324UG-TL-E B 71.3/38.4
Q4 1530002601 S.TRA 2SC4215-O(TE85R,F) T 64.5/25.3
Q5 1590000430 S.TRA DTC144EUA T106 T 55.6/15.2
Q9 1530003340 S.TRA 2SC3357-T1 RF B 88.5/55.2
Q10 1530003260 S.TRA 2SC5006-T1 B 93.8/33.8
Q11 1530003260 S.TRA 2SC5006-T1 B 100.7/32.8
Q12 1530003260 S.TRA 2SC5006-T1 B 97.4/31
Q13 1530002920 S.TRA 2SC4226-T1 R25 B 105.4/32.9
Q14 1530002920 S.TRA 2SC4226-T1 R25 B 100.6/25.8
Q15 1590001400 S.TRA XP1214(TX) T 101.2/34.2
Q16 1590000430 S.TRA DTC144EUA T106 T 103.6/36.6
Q17 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 107.7/33.4
Q18 1560000541 S.FET 2SK880-Y(T5RICOM,F) T 78/24.5
Q19 1590000430 S.TRA DTC144EUA T106 T 99.5/12.9
Q20 1530002851 S.TRA 2SC4116-BL(TE85R,F) [USA-01] T 60/49.8
1530002851 S.TRA 2SC4116-BL(TE85R,F) [EXP-02]
1530002851 S.TRA 2SC4116-BL(TE85R,F) [CHN-01]
Q23 1550000190 S.FET 2SJ506STR-E T 115.3/45.4
Q24 1590000430 S.TRA DTC144EUA T106 T 110.5/44.3
Q25 1540000550 S.TRA 2SD1664 T100Q B 125.1/47.6
Q26 1510000920 S.TRA 2SA1577 T106 Q T 107.7/44.3
Q27 1520000460 S.TRA 2SB1132 T100 R B 123.5/21.1
Q28 1590001190 S.TRA XP6501-(TX).AB B 118.7/22.2
Q29 1590001050 S.TRA DTC114TUA T106 B 126.4/43.3
Q30 1590000430 S.TRA DTC144EUA T106 T 107.7/39.4
Q31 1590001451 S.FET 2SJ144-GR (TE85R,F) B 114.3/13.1
Q33 1590000430 S.TRA DTC144EUA T106 T 113.6/26.6
Q34 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 67.6/25.1
Q35 1590000990 S.TRA DTC363EK T146 B 128.9/17.8
Q36 1590000430 S.TRA DTC144EUA T106 B 118.7/18.3
Q37 1590000430 S.TRA DTC144EUA T106 T 112.5/15
Q39 1590001650 S.TRA XP4601(TX) T 25.2/19.5
Q40 1590001330 S.TRA DTA114EUA T106 T 46.6/33
Q43 1560001360 S.FET 2SK3019 TL T 52.1/27.7
Q44 1590000680 S.TRA DTC114EUA T106 T 36.4/15.2
D1 1790001211 S.DIO 1SS375-TL-E B 21.8/54.2
D3 1710001061 DIO L407CDB
D4 1750000721 S.VAR HVC375BTRF-E B 33.3/38.3
D5 1750001360 S.DIO L709CER (9401) [USA-01] T 24.7/53.6
1750001360 S.DIO L709CER (9401) [EXP-02]
1750001360 S.DIO L709CER (9401) [CHN-01]
D6 1750000581 S.DIO 1SV307(TPH3,F) B 24.8/46.8
D8 1750000721 S.VAR HVC375BTRF-E B 30.5/38.3
D9 1750000711 S.VAR HVC350BTRF-E B 53.8/39.9
D10 1750000711 S.VAR HVC350BTRF-E B 56.6/39.9
D11 1790001211 S.DIO 1SS375-TL-E B 8.2/49.9
D12 1790001211 S.DIO 1SS375-TL-E B 42/58.2
D14 1790001261 S.DIO MA2S077G0L B 83.4/41.8
D15 1790001261 S.DIO MA2S077G0L B 83.2/39.3
D16 1750000771 S.VAR HVC376BTRF-E B 107.2/22.1
D18 1750001570 S.VAR HVL355CMKRF-E B 104.1/25.8
D22 1790000700 DIO DSA3A1
D23 1750000370 S.DIO DA221 TL B 124/43.3
D26 1790001251 S.DIO MA2S1110GL B 116.7/12
D28 1790001241 S.DIO MA2S7280GL T 63.8/52.8
D29 1790001251 S.DIO MA2S1110GL B 119.2/20.2
D31 1750000771 S.VAR HVC376BTRF-E B 105.6/23.2
D33 1750000771 S.VAR HVC376BTRF-E B 91.4/22.2
D34 1750000771 S.VAR HVC376BTRF-E B 93.9/22.2
D37 1790001251 S.DIO MA2S1110GL T 79.9/33.4
D42 1160000140 S.DIO DAP222 TL B 37.1/7.2
D43 1160000140 S.DIO DAP222 TL B 35/7.2
D44 1790001251 S.DIO MA2S1110GL B 48.9/5.4
D45 1790001251 S.DIO MA2S1110GL B 51.5/5.4
D47 1750000581 S.DIO 1SV307(TPH3,F) [EUR-01] T 21.4/52
1750000581 S.DIO 1SV307(TPH3,F) [EXP-01]
D48 1750000581 S.DIO 1SV307(TPH3,F) [EUR-01] T 21.4/53.8
1750000581 S.DIO 1SV307(TPH3,F) [EXP-01]
D52 1750000721 S.VAR HVC375BTRF-E B 99.7/22.1
D53 1750000721 S.VAR HVC375BTRF-E B 103/28.1
D54 1790001261 S.DIO MA2S077G0L B 90.6/33.6
D55 1790001261 S.DIO MA2S077G0L B 91.8/33.6
D56 1750001070 S.DIO DAN235ETL T 51.5/33.5
D57 1750001070 S.DIO DAN235ETL T 48.2/30.4
S.=Surface mount
[MAIN-A UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
D58 1750000370 S.DIO DA221 TL B 113.7/10.8
D59 1750000370 S.DIO DA221 TL T 113/7.1
D60 1750000370 S.DIO DA221 TL B 113/8.4
D61 1750000370 S.DIO DA221 TL T 113/9.4
D62 1750000370 S.DIO DA221 TL T 33.7/37.1
D63 1790001241 S.DIO MA2S7280GL T 31.8/39.7
FI1 2030000150 S.MON DSF753SB 46.350 MHz(FL-335) T 66.6/34.9
FI2 2020002410 CER LTM450FW <JJE>
FI3 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/58.1
FI4 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) B 97.7/61.6
FI5 2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [USA-01] B 97.7/64.9
2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [EXP-02]
2040001440 S.LC NFE31PT152Z1E9L
(NFM60R20T152) [CHN-01]
FI6 2020002460 CER LTM450GW <JJE>
X1 6070000300 S.DIS JTBM450CX24 <JJE> B 52.4/24.5
X2 6050012050 S.XTA CR-794 TTS14VSB-A6 15.3 MHz B 80.8/23.8
L1 6200010050 S.COI AS080547-47N B 9.4/62.7
L2 6200010050 S.COI AS080547-47N B 12.7/56.4
L3 6200010050 S.COI AS080547-47N B 25.4/58.6
L4 6200010050 S.COI AS080547-47N T 30/51.1
L5 6200010420 S.COI FHW1210HC 1R0JGT <JJE> T 39.2/57.9
L6 6200010720 S.COI C2520C-56NG-A B 26.7/49.7
L7 6200011410 S.COI C2520C-82NG-A B 28.2/39.9
L8 6200011410 S.COI C2520C-82NG-A B 35.6/38.3
L9 6200010720 S.COI C2520C-56NG-A B 49/39.8
L10 6200004660 S.COI MLF1608A 1R8K-T T 78.4/13.3
L11 6200010720 S.COI C2520C-56NG-A B 58.9/40.5
L13 6200010090 S.COI ELJND R82JF B 68.1/40.6
L16 6200010050 S.COI AS080547-47N B 38.7/64.5
L21 6200011021 S.COI ELJRF 82NJFB B 92.7/35.3
L22 6200011011 S.COI ELJRF 68NJFB B 99/34.3
L23 6200007001 S.COI ELJRE 82NGFA B 85.9/59.3
L25 6200013020 S.COI 0.25-1.9-7TL 61N <COMO> B 107/28.7
L26 6200009910 S.COI C6342A-88NG-A B 93.6/26.2
L27 6200002001 S.COI NLV25T-3R3J B 104/20
L28 6200007850 S.COI ELJNC R82K-F B 94.3/19.7
L31 6200010000 S.COI C2012C-56NG-A B 24.8/44.8
L32 6200007901 S.COI ELJRF 22NJFB B 82.8/32.8
L33 6200004480 S.COI MLF1608D R82K-T B 62.9/23.3
L35 6200003540 S.COI MLF1608D R22K-T B 65.3/23.3
L36 6200006981 S.COI ELJRE R10GFA B 73.5/38.4
L37 6200005550 S.COI ELJFC 100K-F B 96.8/19.7
L38 6200013020 S.COI 0.25-1.9-7TL 61N <COMO> B 107/20
L39 6200012760 S.COI 0.35-1.6-7TL 37.5N <COMO> B 91.5/19.7
L41 6200007911 S.COI ELJRF 18NJFB B 95.8/31
L43 6200005741 S.COI ELJRE 47NGFA B 88.6/59.3
L44 6200007901 S.COI ELJRF 22NJFB B 84.5/32.8
L45 6200007911 S.COI ELJRF 18NJFB B 85.4/31.5
L46 6200002001 S.COI NLV25T-3R3J T 97.4/19.5
L47 6200002861 S.COI NLV25T-4R7J T 102.8/24.4
L53 6200003640 S.COI MLF1608E 100K-T B 106.8/24.6
L54 6200007120 S.COI ELJND 1R0J T 100.1/31.1
R1 7030000620 S.RES MCR10EZHJ 100 K (104) B 17.4/64.6
R4 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 18.8/54.2
R5 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 24.1/53.8
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [USA-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [EXP-02]
7030005070 S.RES ERJ2GEJ 683 X (68K) [CHN-01]
R6 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 11.2/49.6
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [USA-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [EXP-02]
7030005070 S.RES ERJ2GEJ 683 X (68K) [CHN-01]
R7 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 8.2/53.2
R8 7030006070 S.RES ERJ12YJ101U (100) B 45.7/51.9
R9 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 38.6/58.6
R10 7030005060 S.RES ERJ2GEJ 333 X (33K) [EUR-01] B 44.8/57.9
7030005060 S.RES ERJ2GEJ 333 X (33K) [EXP-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [USA-01]
7030005070 S.RES ERJ2GEJ 683 X (68K) [EXP-02]
7030005070 S.RES ERJ2GEJ 683 X (68K) [CHN-01]
R11 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.9/38.4
R12 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.2/39.5
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 31.9/39.7
R14 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.9/35.5
R15 7030005700 S.RES ERJ2GEJ 274 X (270K) B 39.2/38.6
R16 7030008280 S.RES ERJ2GEJ 271 X (270) B 39.5/40.7
R17 7030004980 S.RES ERJ2GEJ 101 X (100) B 51.5/40.2
R19 7030005090 S.RES ERJ2GEJ 104 X (100K) B 39.2/36.8
R20 7030009200 S.RES ERJ2GEJ 390 X (39) B 52.7/38.7
R21 7030005050 S.RES ERJ2GEJ 103 X (10K) B 55.2/40.2
R22 7030005050 S.RES ERJ2GEJ 103 X (10K) B 63.7/36.7
R23 7030005050 S.RES ERJ2GEJ 103 X (10K) B 55.2/41.3
R26 7030005000 S.RES ERJ2GEJ 471 X (470) B 79/40.6
