4
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
n Programmable function keys
The following functions can be assigned to [DIAL]*, [UP],
[DOWN], [P0], [P1], [P2], [P3] and [P4] programmable func-
tion keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function depends on the programming.
* The functions you can assign to [DIAL] are limited.
(Only functions marked with ✩ can be assigned.)
✩ CH UP AND DOWN KEYS
➥ Push (or Rotate)* to select an operating channel.
➥ Push (or Rotate)* to select a scan group after pushing
and holding [Scan].
* Rotate when this function is assigned to [DIAL].
✩
ZONE UP AND DOWN KEY (This function is for [DIAL] only)
Rotate to select the desired zone.
ZONE KEY
Push this key, then push [CH Up] or [CH Down] or rotate [CH
Up/Down]* to select the desired zone.
What is “zone”?—The desired channels are assigned
into a zone according to the intended use for grouping.
For example, ‘Staff A’ and ‘Staff B’ are assigned into a
“Business” zone, and ‘John’ and ‘Cindy’ are assigned into
a “Private” zone.
SCAN KEY
➥
Push to start and cancel scanning operation.
•WhenthePowerONScanorAutoScanfunctionstartsascan,
push this key to cancel the scan. The canceled scan resumes
after a specified time period.
➥ P
ush and hold this key for 1 sec. to indicate a scan group,
then push [CH Up] or [CH Down] or rotate [CH Up/Down]*
to select the desired one. (Depending on the pre-setting.)
*Simple type only
