6 - 4
S.=Surface mount
C231 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C232 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C233 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C234 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C236 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C243 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C245 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C246 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C247 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C248 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C249 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C250 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C251 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C252 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C256 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C258 4030011600 S.CERAMIC C1608 JB 1C 104KT-N [ANI] only
C260 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C264 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C272 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C278 4550006680 S.TANTALUM ECST0JY156R
C279 4030007120 S.CERAMIC C1608 CH 1H 820J-T-A
C281 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C285 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C290 4030009000 S.CERAMIC C2012 JB 1C 224K-T-A
C291 4550006150 S.TANTALUM ECST1CY105R
C295 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C296 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C298 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C299 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C300 4550006650 S.TANTALUM ECST1CY685R
J2 6450001680 CONNECTOR HSJ1122-010010
J3 6450001690 CONNECTOR HSJ1456-01-220
J4 6450000870 CONNECTOR HEC2711-01-020
J5 6510007080 CONNECTOR PI28A-02M
J6 6910010850 CONNECTOR IMSA-9230B-1-05Z080-T
DS1 5030001460 LCD LM-1462B
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
DS4 5040002190 S.LED LNJ808R8ERA
MC1 7700002160 MICROPHON KUC3523-040245
S1 2230000900 S.SWITCH JPM1990-2013R
W1 7030003860 S.JUMPER ERJ3GE JPW V
W10 7030003860 S.JUMPER ERJ3GE JPW V
EP1 910050712 PCB B 5193B
EP2 8930042590 LCD CONTACT SRCN-1922-SP-N-W
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
Q6 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q7 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q8 1530002920 S.TRANSISTOR 2SC4226-T2 R25
D5 1720000370 S.VARICAP HVU350TRF
D6 1790000620 S.DIODE MA77 (TX)
L10 6200006670 S.COIL ELJRE 68NG-F
L11 6130002760 S.COIL LB-312
L12 6200004480 S.COIL MLF1608D R82K-T
R22 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R23 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R24 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R25 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R26 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R27 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R28 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R29 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C37 4030009510 S.CERAMIC C1608 CH 1H 010B-T-A
C38 4030009510 S.CERAMIC C1608 CH 1H 010B-T-A
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C40 4030009510 S.CERAMIC C1608 CH 1H 010B-T-A
C41 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C45 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C259 4030007160 S.CERAMIC C1608 CH 1H 181J-T-A
J1 6910010840 CONNECTOR IMSA-9230B-1-05Z057-T
EP1 910050691 PCB B 5195A
R1 7210002950 VARIABLE RV-312 (RK0971110)
C1 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
EP1 910050701 PCB B 5196A
REF ORDER
DESCRIPTION
NO. NO.
[VCO BOARD]
[VR BOARD]
REF ORDER
DESCRIPTION
NO. NO.
