SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q1351 1590000430 S.TR DTC144EUA T106 B 35.6/32.9
Q1352 1590000430 S.TR DTC144EUA T106 B 48.2/89.4
Q1460 1530002280 S.TR 2SC4081 T106 S T 5.9/75.3
Q1550 1560000830 S.FET 2SK2036 (TE85L) B 10.3/70
Q1600 1540000250 S.TR 2SD999-T2 CK B 110.1/19.2
Q1603 1530002280 S.TR 2SC4081 T106 S T 108.6/20.1
Q1670 1590001450 S.FET 2SJ144-GR (TE85R) T 98.1/16.1
Q1671 1590000430 S.TR DTC144EUA T106 T 96/12.9
Q1673 1530002280 S.TR 2SC4081 T106 S T 92.8/16.4
Q1750 1520000200 S.TR 2SB798-T2 DK B 23.2/114.9
Q1751 1530002280 S.TR 2SC4081 T106 S T 26.5/119.1
Q1800 1590000430 S.TR DTC144EUA T106 T 11/24.8
D131 1790001620 S.DIO 1SV308 (TPL3) T 39.3/52.9
D192 1750000360 S.DIO 1SS364 (TE85L) B 49.5/25.5
D193 1750000360 S.DIO 1SS364 (TE85L) B 56.9/14.7
D194 1750000550 S.DIO 1SS355 TE-17 T 55.3/39.4
D195 1790001560 S.DIO 1SS372 (TE85R) T 63.3/33.2
D272 1790000490 S.DIO HSM88AS-TR B 83.7/39.9
D273 1790001620 S.DIO 1SV308 (TPL3) B 41.1/52.5
D274 1790000490 S.DIO HSM88AS-TR B 73.9/49.3
D401 1730002260 S.ZEN MA8030-H (TX) B 22.4/58
D470 1730002360 S.ZEN MA8062-M (TX) T 14.1/69.1
D471 1720000470 S.VCP 1SV239 (TPH3) T 20.8/76.9
D630 1720000690 S.VCP 1SV282 (TPH2) T 13.8/41.3
D631 1720000400 S.VCP 1SV245 (TPH3) T 16.6/31
D632 1790001260 S.DIO MA2S077-(TX) T 13.6/35.9
D633 1730002300 S.ZEN MA8082-M (TX) T 35.3/38.7
D710 1790001620 S.DIO 1SV308 (TPL3) B 41.8/64.6
D711 1790001620 S.DIO 1SV308 (TPL3) B 41.5/69.5
D770 1750000580 S.DIO 1SV307 (TPH3) B 31.2/39.9
D771 1750000580 S.DIO 1SV307 (TPH3) B 29/44.3
D1080 1730002300 S.ZEN MA8082-M (TX) B 83.1/67.6
D1160 1750000760 S.DIO MA4PH224 T 90.9/106.4
D1161 1750000760 S.DIO MA4PH224 T 81/108.5
D1162 1750000760 S.DIO MA4PH224 T 77.8/111.5
D1164 1720000360 S.DIO HSU88TRF T 88.4/121.8
D1165 1720000360 S.DIO HSU88TRF B 93.1/126.3
D1166 1720000360 S.DIO HSU88TRF T 95.7/109.5
D1168 1790001040 S.ZEN MA8033-L (TX) B 64.7/119.1
D1169 1790001040 S.ZEN MA8033-L (TX) B 64.7/122.4
D1170 1720000360 S.DIO HSU88TRF T 111.9/118
D1250 1720000360 S.DIO HSU88TRF T 69.1/124.2
D1251 1720000360 S.DIO HSU88TRF B 71.6/121.4
D1252 1720000360 S.DIO HSU88TRF B 74.6/120.2
D1254 1790001260 S.DIO MA2S077-(TX) B 80/121.3
D1330 1790000700 DIO DSA3A1 T 50.6/120.4
D1331 1750000550 S.DIO 1SS355 TE-17 B 68.1/70.7
D1332 1750000550 S.DIO 1SS355 TE-17 T 27.3/92
D1333 1750000550 S.DIO 1SS355 TE-17 T 29.1/92
D1600 1730002280 S.ZEN MA8091-M (TX) B 111.9/23.8
D1602 1730002280 S.ZEN MA8091-M (TX) B 105.9/11
D1604 1750000550 S.DIO 1SS355 TE-17 T 108.2/14.6
D1605 1730002280 S.ZEN MA8091-M (TX) B 111.9/12.4
D1606 1730002280 S.ZEN MA8091-M (TX) B 99.7/12.6
D1750 1730002300 S.ZEN MA8082-M (TX) T 26.4/121.3
D1800 1750000550 S.DIO 1SS355 TE-17 T 13.5/23.2
D1801 1750000550 S.DIO 1SS355 TE-17 T 8.6/22.3
FI1 2040001660 S.FIL LFB431G28SN1A362 T 51.3/100.6
FI2 2040001660 S.FIL LFB431G28SN1A362 T 48.5/86.2
FI71 2040001650 S.SAW WF447B-T T 47.2/67.9
FI191 2010002440 S.XTL FL-312 (31.05 MHz) T 45.6/43.1
FI192 2020001920 CER CFWLB450KE1Y-B0 T 61.5/22
FI193 2020001460 CER CFWLA450KHFA-B0 T 64.1/16.3
FI272 2020001160 CER SFELA10M7HA0G-B0 T 59.7/46.2
FI273 2020001160 CER SFELA10M7HA0G-B0 T 68.9/46.2
FI880 2040001650 S.SAW WF447B-T T 51.2/52.5
FI961 2040001360 S.FIL LFB431G27AL1A303 T 63.6/62.6
FI1020 2040001360 S.FIL LFB431G27AL1A303 T 85/48.4
X191 6070000190 S.DCR CDBCB450KCAY24-R0 T 57.5/28.1
X271 6070000070 DCR CDALA10M7CA004A-B0 T 73.4/35.5
X400 6050010930 S.XTL CR-662 (15.3 MHz) T 14.3/55.1
L1 6200006030 S.COL LQP18MN4N7C00D T 66.8/105.6
L2 6200006020 S.COL LQP18MN3N9C00D T 64.7/108.8
L3 6200006030 S.COL LQP18MN4N7C00D T 60.5/105.3
L4 6200006060 S.COL LQP18MN8N2C00D T 59.2/105.3
L5 6200006040 S.COL LQP18MN5N6C00D T 56.6/102.5
L6 6200006050 S.COL LQP18MN6N8C00D T 49.4/95.4
L7 6200009950 S.COL LQP18MN3N3C00D T 55.2/90.6
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC71 1110004470 S.IC µPC2721GV-E1 T 45.5/76.4
IC191 1110003490 S.IC TA31136FN (D,EL) T 46.5/29.9
IC271 1110004070 S.IC MC3356DW-R2 T 81.8/33.5
IC341 1130008090 S.IC BU4066BCFV-E1 T 92.5/35.1
IC342 1130006220 S.IC TC4W53FU (TE12L) T 106.9/33.8
IC343 1110005290 S.IC NJM2115V-TE1 T 98.2/28.2
IC345 1130004200 S.IC TC4S66F (TE85R) T 66.3/33.4
IC400 1130010100 S.IC LMX2352TMX B 25.6/64.8
IC550 1130007610 S.IC µPD3140GS-E1 (DS8) B 12.7/35
IC551 1130006220 S.IC TC4W53FU (TE12L) B 21/43.6
IC830 1110006090 S.IC XC6202P502PR B 38.3/28.2
IC831 1110002750 S.IC TA75S01F (TE85R) B 62/33.4
IC832 1110004050 S.IC NJM3404AV-TE1 B 57.9/32.6
IC890 1110005410 S.IC RF2485 B 48.5/41.7
IC960 1110005150 S.IC µPC8163TB-E3 B 53.3/61.8
IC1021 1110001890 S.IC µPC1678G-E2 T 68.1/53.9
IC1250 1110002750 S.IC TA75S01F (TE85R) B 78.9/124.3
IC1251 1110002750 S.IC TA75S01F (TE85R) B 80.1/116
IC1330 1180002080 S.REG BA09FP-E2 B 75.3/89
IC1331 1180001070 S.IC TA7805F (TE16L) B 77/100.9
IC1332 1180002020 S.REG BA033FP-E2 B 36.4/96.1
IC1411 1130006220 S.IC TC4W53FU (TE12L) T 41.4/20.4
IC1460 1110003780 S.IC NJM2902V-TE1 T 41.4/14.6
IC1461 1110003780 S.IC NJM2902V-TE1 B 49.3/8.4
IC1462 1130006220 S.IC TC4W53FU (TE12L) B 42.1/14.6
IC1463 1130006220 S.IC TC4W53FU (TE12L) B 59.2/6.2
IC1550 1110003300 S.IC M5282FP 70CD B 12.2/56
IC1551 1110003090 IC LA4425A T 2.3/62
IC1670 1130006220 S.IC TC4W53FU (TE12L) T 84.6/14.1
IC1671 1110004050 S.IC NJM3404AV-TE1 B 80.2/20.3
IC1672 1110005310 S.IC AN6123MS T 74.7/12.9
IC1673 1130006220 S.IC TC4W53FU (TE12L) B 75.7/14.6
Q1 1590002940 S.FET NE34018-T1 T 57.3/105.2
Q2 1530003660 S.TR 2SC5454-T1 R54 T 52.2/90.4
Q131 1580000680 S.FET 3SK241-R (TX) T 41.9/58.9
Q191 1530002600 S.TR 2SC4215-O (TE85R) T 45.4/35.3
Q192 1530002280 S.TR 2SC4081 T106 S T 56.7/32.9
Q193 1530002280 S.TR 2SC4081 T106 S T 59.4/35.7
Q270 1530002600 S.TR 2SC4215-O (TE85R) T 66.1/41.6
Q271 1530002600 S.TR 2SC4215-O (TE85R) B 79/42.6
Q272 1590000720 S.TR DTA144EUA T106 T 60.4/41.9
Q341 1590000720 S.TR DTA144EUA T106 T 54.1/11.1
Q342 1590000430 S.TR DTC144EUA T106 T 69.4/32.9
Q400 1530002920 S.TR 2SC4226-T1 R25 T 23.2/52.5
Q470 1540000660 S.TR 2SD2216J-S T 14.6/74.6
Q471 1530003560 S.TR 2SC5195-T1 T 25.6/73.1
Q472 1530003560 S.TR 2SC5195-T1 T 23.5/73.3
Q473 1530002920 S.TR 2SC4226-T1 R25 T 29.9/67.7
Q474 1530003310 S.TR 2SC5107-O (TE85R) B 28.9/72.8
Q550 1530002280 S.TR 2SC4081 T106 S T 25.3/48.5
Q630 1590000430 S.TR DTC144EUA T106 T 8/27.7
Q631 1530002920 S.TR 2SC4226-T1 R25 T 23.7/32.8
Q632 1530002920 S.TR 2SC4226-T1 R25 T 29/30.2
Q633 1530002920 S.TR 2SC4226-T1 R25 B 26.3/29.8
Q634 1540000660 S.TR 2SD2216J-S T 30.3/35
Q710 1530003310 S.TR 2SC5107-O (TE85R) B 38.6/73.3
Q770 1590001330 S.TR DTA114EUA T106 B 34.1/58.9
Q771 1530002920 S.TR 2SC4226-T1 R25 T 26.5/39.9
Q890 1530003310 S.TR 2SC5107-O (TE85R) B 35.3/39.4
Q1080 1560001090 S.FET 2SK2854 B 98.4/39.4
Q1081 1560001140 S.FET 2SK2855 (TE12L) B 108.6/38.2
Q1082 1540000470 S.TR 2SD1801S-TL B 76.3/65.4
Q1250 1590000430 S.TR DTC144EUA T106 B 64.7/127.1
Q1330 1590001320 S.TR DTC143ZUA T106 B 63.8/108.7
Q1331 1510000890 S.TR DTA143TU T106 B 63.8/105.3
Q1332 1530002970 S.TR 2SC4684 (TE16R) B 63.4/98.6
Q1333 1520000730 S.TR 2SB934P (DS) -(TX) B 76.3/75.5
Q1334 1530002280 S.TR 2SC4081 T106 S B 63.1/74.7
Q1335 1590000430 S.TR DTC144EUA T106 B 62.8/71.6
Q1336 1540000440 S.TR 2SD1619-T-TD B 26.6/95.1
Q1337 1510000580 S.TR 2SA1362-GR (TE85R) B 37/89.7
Q1338 1590000430 S.TR DTC144EUA T106 T 27.5/95.2
Q1340 1590000430 S.TR DTC144EUA T106 T 25/95.2
Q1341 1590000430 S.TR DTC144EUA T106 T 35.4/96.8
Q1342 1510000580 S.TR 2SA1362-GR (TE85R) B 40.2/87.8
Q1343 1510000580 S.TR 2SA1362-GR (TE85R) B 42.9/93.8
Q1344 1590000430 S.TR DTC144EUA T106 T 44.6/89.2
Q1345 1590000430 S.TR DTC144EUA T106 B 63.4/57.8
Q1346 1590000430 S.TR DTC144EUA T106 B 63.5/51.9
Q1347 1590000430 S.TR DTC144EUA T106 B 66.1/53.7
Q1348 1510000580 S.TR 2SA1362-GR (TE85R) B 55.2/55.7
Q1349 1510000580 S.TR 2SA1362-GR (TE85R) B 60.9/55.4
Q1350 1510000580 S.TR 2SA1362-GR (TE85R) B 39.9/34.3
S.=Surface mount
