Operation
•
IDEAL 4810-95 • IDEAL 4850-95/EP • IDEAL 5221-95EP • IDEAL 6550-95EP
Programming
Only IDEAL 4850-95EP, IDEAL 5221-95EP,
DEAL 6550-95EP
This control system enables you to store 99
programs with 99 programmable steps. One
step represents one measurement. After
entering the program numbers you are able to
change between several program steps with
the button
j
and
b
.
First figure on display = program number.
Second figure = program step.
Dimensions below 9 cm/3,54 inch can only
be approached with the
S
button held pressed.
"
u" on the display the entered dimension is
too low.
"
o" on the display the entered dimension is
too high.
Each program step corresponds to one
dimension. The indicated program step can be
overwritten at any time. These programs
remain stored when the machine is off. Should
you change to another dimension unit all
programmed measurements are converted into
the new unit (cm or inch).
Entering a program
• Press
p
P appears on the display.
•
01
...
99
Enter program number 01 ... 99.
(Top number
V
on display = program number).
• If measurement is shown on the display
K
the
program is reserved.
•
Enter dimension, or move the backgauge to
the desired measurement with the
hand-wheel
G
.
•
g
Store the dimension next program step
appears
W
.
•
Enter the next dimension.
Should an ejection be desired before this cut
press
p
, hold, and press
T
.
•
g
Store the dimension next program step
appears.
•
Should the entered program be required
immediately press
S
(program is closed).
Press
S
again (backgauge moves to the
dimension of the first program).
Or:
•
p
+
s
Escape the program mode.
