Fig. 48 - Front View EXALT Solo 110

102

CHAPTER 19

CHAPTER 19 - PRODUCT SPECIFICATIONS

A B C D E F G H I J K

Item

Boiler

Width

3" Com-

bustion Air

Inlet

3" Vent

Outlet

/" NSPC

Relief

Valve

Vent\Com-

bustion Air

Connection

Height

Boiler

Height

1" NPT

Boiler

Supply

1" NPT

Boiler

Return

/" Gas

Connection

Conden-

sate Drain

Conden-

sate Height

Dimension

inches

[mm]

21 /

[550]

3 /

[100]

17 /

[445]

2 /

[57]

5 /

[130]

[660]

2 /

[57]

4 /

[120]

4 /

[110]

17 /

[440]

6 /

[171]
