Fig. 56 - Front View EXALT Combi 199

110

CHAPTER 19

CHAPTER 19 - PRODUCT SPECIFICATIONS

A B C D E F G H I J K L

Connection

Boiler

Width

3” Com-

bustion Air

Inlet

3” Vent

Outlet

/” NPSC

Relief Valve

Vent/Combus-

tion Air Adapt-

er Height

Boiler

Height

1" NPT Boil-

er Supply

1" NPT Boil-

er Return

/" NPT

Gas Con-

nection

Conden-

sate Drain

/" NPT

DHW

Supply

/" NPT

DHW

Inlet

Dimension

inches

[mm]

21 /

[550]

3 /

[85]

18 /

[475]

2 /

[50]

5 /

[130]

32 /

[830]

19 /

[500]

2 /

[70]

[280]

15 /

[390]

16 /

[425]

5 /

[145]
