43

CHAPTER 7

CHAPTER 7 - GAS PIPING

Fig. 28 - Gas Valve / Venturi Assembly - EXALT Solo/Combi 199

Air reference Hose

Air Inlet

Venturi

Gas Valve

Pipe to Venturi

Venturi interface
