Note.
A at or pitched roof ashing plate (not supplied) is required before
proceeding with the installation of this kit.
This kit is suitable for both at and
pitched roof terminations, using a
concentric ue to run vertically from the
top of the boiler and terminating above
roof level.
Connection to the top of the boiler
is made using the supplied vertical
connector.
WEATHER PROOFING
Where the ue passes through the roof
line an adequate seal must be made.
This is achieved by using either:
- Flat roof weather collar
or
- Universal weather collar.
ACCESSORIES
Flue Duct Extension Kits are available
for ue lengths extending beyond 1m.
These packs contain 1m extension ducts
and may be cut to the desired length.
If the offset vertical option is used
an elbow Kit is required. For a full
accessories list refer to page 6, Optional
Extras and Frame 25, Flue Arrangement.
18
ROOF FLUE KIT CONTENTS / OPTIONS
17
FITTING THE OPTIONAL ROOF FLUE KIT (Flat or Pitched)
