GENERAL
CONTENTS
Boiler Models..................................................................4
Packing ...........................................................................5
Installation ......................................................................6
Assembly/Hydraulic Connection ..................................7
Filling the Installation.....................................................8
Desludging/Chimney Connection.................................9
Dimensions/Connection ..............................................10
Oil or Gas Connection .................................................11
Control Panels..............................................................12
Start Up .........................................................................16
Maintenance .................................................................19
Precautions...................................................................20
Data Table .....................................................................21
Main Dimensions..........................................................22
2
INTRODUCTION
DUTY
The range of boilers is suitable for: combined indirect pumped
domestic hot water and central heating systems; independent
indirect pumped domestic hot water or central heating
systems.
Fully pumped systems may be open vented or sealed.
The range of boilers is NOT suitable for:
1. Gravity DHW systems.
2. Gravity heating systems.
3. Direct domestic hot water supply.
GAS SAFETY (INSTALLATION AND USE)
REGULATIONS, 1994
It is law that all gas appliances are installed and serviced by a
CORGI registered installer in accordance with the above
regulations. Failure to install appliances correctly could lead to
prosecution. It is in your own interest, and that of safety, to
ensure the law is complied with.
The installation of the boiler MUST also be in accordance with
the latest l.E.E Wiring Regulations, local building regulations,
bye-laws of the local water authority, the building regulations
and the Building Standards (Scotland) and any relevant
requirements of the local authority.
Detailed recommendations are contained in the following
British Standard Codes of Practice:
BS. 6891 Low pressure installation pipes.
BS. 6798 Installation of gas fired hot water boilers of rated
input not exceeding 60 kW.
BS. 5449 Forced circulation hot water systems.
BS. 5546 Installation of gas hot water supplies for
domestic purposes (2nd Family Gases)
BS. 6644 Ventilation (for gas appliances of rated input
exceeding 60 kW)
BS. 5440:2 Ventilation (for gas appliances of rated input not
exceeding 60 kW)
Viceroy GT Range - Installation
FOUNDATION
The boiler must stand on a non-combustible floor
(i.e. concrete or brick) which must be flat, level and of a
suitable load bearing capacity to support the weight of the
boiler (when filled with water) and any ancillary equipment.
If the boiler is mounted on a plinth then the dimensions must
exceed the plan area of the boiler by at least 75mm on each
side
