MD021 Plastic Wire Drawing Machine User Manual
Group F1: Input/Output Terminals
The inverter for the plastic wire drawing machine is configured with
two multi-function digital input terminals DI1 and DI2, one analog
input terminal AI, a fault output relay, and a DO output terminal.
The DI terminals can be allocated with the functions listed in the
following table. Note that a function must not be repeatedly selected.
If a certain function cannot be selected, check whether the function is
used by another terminal.
The input DI has no function.
When "Command source selection"
(F0-00) is set to 1 (Terminal input),
To Next Page
