Chapter 6 Parameter Description
-61-
acceleration time of F0-05 and maintain for
certain period of time. Then the motor will
decelerate to zero speed in accordance with
the setup acceleration time of F0-06, and by
this time the rotary tuning is completed.
Action description: Set the function code to 2
and press RUN key for confirmation, and then
the inverter will conduct rotary tuning.
Tuning operation description:
When F1-11 is set to 1 or 2, press ENTER key
and “TUNE” will be displayed and flashes.
Press RUN key to conduct parameter tuning,
and at this time the displayed “TUNE” stops
flashing, “TUNE/TC” LED flash. After the
tuning is completed, the display will return to
the stop status interface. When “TUNE”
flashes, press PRG to exit from tuning status.
The tuning process can be stopped by
pressing the STOP key. When the tuning is
completed, the value of F1-11 will
automatically restore to 0.
Group F2 Vector and VF
Control Parameters
Function codes from F2-00WRF2-08 are only
enabled to the vector control, that is, it is valid
when F0 – 00 = 0.
Function codes from F2-09WRF2-10 are only
enabled to the V/F control, that is, it is valid when
F0 – 00 = 2.
Vector
control
speed loop
proportion
gain 1
Factory
default
value
30
F2-00
Setup range
0100
Vector
control
speed loop
integration
time 1
Factory
default
value
0.50s
F2-01
Setup range
0.01 s10.00 s
Vector
control
switch
frequency 1
Factory
default
value
5.00
Hz
F2-02
Setup range
0.00 F2-05
Vector
control
speed loop
proportion
gain 2
Factory
default
value
25
F2-03
Setup range
0100
Vector
control
speed loop
integration
time 2
Factory
default
value
1.00s
F2-04
Setup range
0.01s 10.00s 
Vector
control
switch
frequency 2
Factory
default
value
10.00
Hz
F2-05
Setup
range
F2-02 maximum
output frequency
F2-00 and F2-01 are PI adjustment
parameters when the running frequency is
lower than switching frequency 1 (F2-02).
F2-03 and F2-04 are PI adjustment
parameters when the running frequency is
higher than switching frequency 2 (F2-05).
PI adjustment parameter between the
switching frequency 1 and switching
