Inovance MD300 Series User Manual

Chapter 6 Parameter Description
-67-
Group F5 Fault and Protection
Motor overload
protection
selection
Factory
default
value
1
F5-00
Setup
range ˖
0: Disabled
1: Enabled
0: The inverter has
no overload
protection for the
motor, and thermal
relay is installed
before the motor.
1: The inverter has
overload protection
function for the
motor. Refer to
F5-01 for the
protection value.
Motor
overload
protection
coefficient
Factory
default
value
1.00
F5-01
Setup range˖
0.2010.00
The motor
overload
protection is
inverter time-lag
curve; (220%) ×
(F5-01) × (rated
motor current):
one minute;
(150%) ×(F5-01)×
(rated motor
current): 60
minutes.
Stall gain
over voltage
Factory
default
value
0
F5-02
Setup
range˖
0(no stall
over
voltage)
WR 100
It adjusts the
inverter’s capacity in
suppressing the stall
over voltage. The
bigger the value is,
the stronger the
suppressing capacity
is. For the load with
small inertia, the
value should be
small. Otherwise, the
dynamic response of
the system will be
slow. For the load
with large inertia, the
value should be
large. Otherwise, the
suppressing result
will be poor, and over
voltage fault may
occur.
Stall point
over voltage
Factory
default
value
130%
F5-03
Setup
range˖
120
150%
Select the protection
point for function of
stall over voltage.
When the value is
exceeded, the
inverter starts
executing the
protection function for
stall over voltage.
